Small Resistance Metal Plank Washable Air Filter Anti Acid For Spray Wax Room
Small Resistance Metal Plank Washable Air Filter Anti Acid For Spray Wax Room
Small Resistance Metal Plank Washable Air Filter Anti Acid For Spray Wax Room
Small Resistance Metal Plank Washable Air Filter Anti Acid For Spray Wax Room
Small Resistance Metal Plank Washable Air Filter Anti Acid For Spray Wax Room
Small Resistance Metal Plank Washable Air Filter Anti Acid For Spray Wax Room
Specifications
Brand Name :
QS
Model Number :
QS-glq-0003
Certification :
Testing Report
Place of Origin :
Suzhou China
MOQ :
20pcs
Price :
Negotiable
Payment Terms :
L/C, D/A, T/T, Western Union, MoneyGram
Supply Ability :
200pcs/day
Delivery Time :
5-8 working days
Packaging Details :
1pcs/bag
Name :
Mental Plank Filter For The Spray-Wax Room
Application :
100 Lab / Laboratory Clean Room
Frame optional thicknessnsion :
50/69/80/93/105/117
Efficient size :
570*570*69, 1170*570*69, 1170*1170*69
Frame :
Aluminum profile, galvanized iron, stainless steel
Suitable in :
used in optical electronic, LED liquid crystal manufacturing, biopharmaceuticals
Divider line :
Hot melt adhesive
Protective mesh surface :
Painted expanded metal mesh
Description

Small Resistance Washable Anti-Acid Mental Plank Filter For The Spray-Wax Room

Product Description:

High efficiency filter can be widely used in optical electronic, LED liquid crystal manufacturing, bio-pharmaceuticals, precision instruments, food and beverage, pcb printing and other industries dust-free purification plant air conditioning terminal air supply.

Main Features:
1) Ultra-fine fiber filter paper is used as the filter media. The outer frame is made of aluminum alloy material, and stainless steel can also be customized as the outer frame material.
2) This high efficiency filter is economical and practical, widely used in food, electronics, semiconductor, pharmaceutical and other industries.
3) The large surface area of the filter can increase the filter area and improve the filtration efficiency.

Specification:

Frame material Galvanized sheet;stainless stell; MDF; Anodized aluminium
Medium Micro glassfiber
Max. Working temperature 80℃,180℃,250℃,300℃
Max. Working Rel. humidity 100%

Specification Size:

Type Boundary Dimension(mm) Effective Filtration Area Air Volume pressure drop
XWB/H14-6601 305*305*66 2.7 245 145
XWB/H14-6602 457*457*66 6.2 610 140
XWB/H14-6603 305*610*66 5.5 500 140
XWB/H14-6604 457*610*66 8.2 820 140
XWB/H14-6605 610*610*66 11.0 1000 140
XWB/H14-6606 610*915*66 16.5 1500 140
XWB/H14-6607 610*1220*66 22.0 2000 140
XWB/H14-6608 610*1524*66 27.5 2500 140
XWB/H14-6609 762*305*66 6.9 630 140
XWB/H14-6610 762*610*66 13.7 1250 140
XWB/H14-6611 762*762*66 17.1 1560 140
XWB/H14-6612 762*1220*66 27.5 2500 140
XWB/H14-6613 915*915*66 24.8 2500 140
XWB/H14-6614 915*1220*66 33.0 3010 140
XWB/H14-8001 305*305*80 2.9 245 105
XWB/H14-8002 457*457*80 6.7 610 100
XWB/H14-8003 305*610*80 6.0 500 100
XWB/H14-8004 457*610*80 9.0 820 100
XWB/H14-8005 610*610*80 12.0 1000 100
XWB/H14-8006 610*915*80 18.0 1500 100
XWB/H14-8007 610*1220*80 24.0 2000 100
XWB/H14-8008 610*1524*80 30.0 2500 100
XWB/H14-8009 762*305*80 7.5 630 100
XWB/H14-8010 762*610*80 14.9 1250 100
XWB/H14-8011 762*762*80 18.6 1560 100
XWB/H14-8012 762*1220*80 30.0 2500 100
XWB/H14-8013 915*915*80 27.0 2500 100
XWB/H14-8014 915*1220*80 36.0 3010 100
XWB/H14-9001 305*305*90 3.4 245 95
XWB/H14-9002 457*457*90 7.8 610 90
XWB/H14-9003 305*610*90 7.0 500 90
XWB/H14-9004 457*610*90 10.4 820 90
XWB/H14-9005 610*610*90 14.0 1000 90
XWB/H14-9006 610*915*90 21.0 1500 90
XWB/H14-9007 610*1220*90 28.0 2000 90
XWB/H14-9008 610*1524*90 35.0 2500 90
XWB/H14-9009 762*305*90 8.8 630 90
XWB/H14-9010 762*610*90 17.4 1250 90
XWB/H14-9011 762*762*90 21.7 1560 90
XWB/H14-9012 762*1220*90 35.0 2500 90
XWB/H14-9013 915*915*90 31.5 2500 90
XWB/H14-9014 915*1220*90 42.0 3010 90
XWB/H14-11001 305*305*110 4.4 245 75
XWB/H14-11002 457*457*110 9.9 610 70
XWB/H14-11003 305*610*110 8.8 500 70
XWB/H14-11004 457*610*110 13.2 820 70
XWB/H14-11005 610*610*110 17.7 1000 70
XWB/H14-11006 610*915*110 26.4 1500 70
XWB/H14-11007 610*1220*110 35.2 2000 70
XWB/H14-11008 610*1524*110 43.9 2500 70
XWB/H14-11009 762*305*110 11.2 630 70
XWB/H14-110010 762*610*110 22.1 1250 70
XWB/H14-110011 762*762*110 27.6 1560 70
XWB/H14-110012 762*1220*110 44.1 2500 70
XWB/H14-110013 915*915*110 39.8 2500 70
XWB/H14-110014 915*1220*110 53.0 3010 70


Small Resistance Metal Plank Washable Air Filter Anti Acid For Spray Wax Room

Small Resistance Metal Plank Washable Air Filter Anti Acid For Spray Wax Room

Small Resistance Metal Plank Washable Air Filter Anti Acid For Spray Wax Room
