F5 Coarse Efficiency Panel Air Filter Metal Mesh Cardboard Frame Customized Size
F5 Coarse Efficiency Panel Air Filter Metal Mesh Cardboard Frame Customized Size
F5 Coarse Efficiency Panel Air Filter Metal Mesh Cardboard Frame Customized Size
F5 Coarse Efficiency Panel Air Filter Metal Mesh Cardboard Frame Customized Size
F5 Coarse Efficiency Panel Air Filter Metal Mesh Cardboard Frame Customized Size
F5 Coarse Efficiency Panel Air Filter Metal Mesh Cardboard Frame Customized Size
F5 Coarse Efficiency Panel Air Filter Metal Mesh Cardboard Frame Customized Size
F5 Coarse Efficiency Panel Air Filter Metal Mesh Cardboard Frame Customized Size
F5 Coarse Efficiency Panel Air Filter Metal Mesh Cardboard Frame Customized Size
F5 Coarse Efficiency Panel Air Filter Metal Mesh Cardboard Frame Customized Size
Specifications
Brand Name :
SAF
Model Number :
SAF-CG
Certification :
CE,ROHS,ISO
Place of Origin :
Shenzhen,China
MOQ :
10pcs
Price :
$4-$15
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10000pcs/month
Delivery Time :
5-10days after receiving the deposit
Packaging Details :
carton
Filter material :
High temperature resistant fiberglass felt
Frame :
Galvanized steel, SS, Aluminum alloy
Application :
Air Conditioning System
Dimension :
Customized or standard size
Grade :
F5 F6 F7 F8
Description

F5 coarse Primary efficiency filter metal mesh cardboard frame air filter replacement

Product introduction:

Air filter performance is measured by dust holding capacity and efficiency. Greater dust holding capacity means longer service life and lower operating costs. Greater efficiency means cleaner air and reduced maintenance costs. The SAF filters (Bag Filters) excel in both of these performance characteristics. We have MERV 14, MERV 13, MERV 11, and MERV 9available in both Synthetic and Fiberglass.

Bag filters are designed for use in areas that demand the highest degree of air cleanliness including hospitals, schools, industrial facilities and office complexes..

The color for different efficiency pocket filters.
F5-white, F6-Green, F7-Pink, F8-Yellow; customized color available.

Main application:

The pocket filters can be used as the final filtration in normal air ventilation systems, be applied in airport, school, library, mall, supermarket. The F8 efficiency pocket filters is enough for particle release in those occasions, it`s no need to add H13 efficiency HEPA filters.Pocket filters consist of synthetic filter media, or glass fiber media, filter frame can be galvanized steel or aluminum alloy.

Technical Parameters:

Model Dimension(mm) Rated air flow (m³/h) Resistance(Pa) Efficiency (Arrestance)
SAF-CG-8 595*595*381*6p 2000 50 40%- 50%
SAF-CG-13 595*595*500*6p 2500 50 40%- 50%
SAF-CG-16 595*595*600*6p 3000 55 60%-70%
SAF-CG-22 595*595*381*8p 2600 60 75%-85%
SAF-CG-27 595*595*500*8p 3200 65 85%-95%
SAF-CG-32 595*595*600*8p 4000 65 85%-95%

The size can be customized according to customers requirement

F5 Coarse Efficiency Panel Air Filter Metal Mesh Cardboard Frame Customized Size

F5 Coarse Efficiency Panel Air Filter Metal Mesh Cardboard Frame Customized Size

F5 Coarse Efficiency Panel Air Filter Metal Mesh Cardboard Frame Customized Size

If you want to know more about our products,feel free to contact me!

Shenzhen Xiangnan High-tech Purification Equipment Co.,Ltd

Website: www.saf-airfilters.com

Mob:+8613421019887

Whatsapp: +8613421019887

Skype: oookkelly

Wechat: 13421019887
