Pink F7 Air Filter Aluminum Alloy Frame , 8 Pockets Air Handler Filters
Pink F7 Air Filter Aluminum Alloy Frame , 8 Pockets Air Handler Filters
Pink F7 Air Filter Aluminum Alloy Frame , 8 Pockets Air Handler Filters
Pink F7 Air Filter Aluminum Alloy Frame , 8 Pockets Air Handler Filters
Specifications
Brand Name :
XNGK
Model Number :
XN-M3
Certification :
CE/ROHS
Place of Origin :
China
MOQ :
1pcs
Price :
negotiation
Payment Terms :
T/T or western Union or LC
Supply Ability :
3,000pcs per month
Delivery Time :
10-20 working days according to the QTY
Packaging Details :
Plastic bag inside, carton box outside, wooden case if required
Product Name :
Synthetic Pocket Air Filter
Application :
HVAC Second Filter
Filter efficiency :
M5-F9 EN:779
Frame :
Aluminum Alloy or gal steel
Size :
Standard or Customized
Feature :
Multi Pocket
Sealant :
Sealed by ultrasonic
Gasket :
Neoprene if required
Final pressure drop :
450Pa
Environment :
80℃
Description

Multi Pocket Design Bag Air Filter High Efficiency for Air Ventilation

Technical parameters:

Dimension Efficiency

Air flow rate / Initial pressure drop

( m3/h / Pa )

Air flow rate / Initial pressure drop

( m3/h / Pa )

 Pockets

Media area

( m2)
592*592*600 F5 2500 / 35 3800 / 50 8 6.5
F6 2500 / 45 3800 / 65
F7 2500 / 80 3800 / 115
F8 2500 / 90 3800 / 135

Pressure drop range: ±15%

According to clients` requirements offer different specifications

Applications:

For clean room HVAC system second filter in electrical factories, food industries, pharmaceutical, LED, laboratory, school, hospital and so on;

Features:

Relatively cheap price than medium efficiency V bank filter, more easily to replace, better performance, larger dust holding ability;

The filter media a multi layered, first layer is designed for collecting dust, last layer is designed for filter fine dust as small as 0.5 micron;

The V style make flow air pass the pocket evenly. make full use of the filter media;

Description:

Normally the pocket qantity is 6 or 8, we can give customized design, the qantity can be 4 - 10 pockets;

pocket length 100mm to 1200mm available;

All the pocket sealed by ultrasonic machine, make sure no air leakage;

All the frame thickness is 21mm, no matter it`s galvanized or aluminum alloy;

filter media and frame connect with each other by glue and rivet;

Filter media color: white, green, pink, yellow, white and so on, customzied color available;
