G3 G4 Primary Pocket Air Filter Washable Synthetic Media High Air Flow
G3 G4 Primary Pocket Air Filter Washable Synthetic Media High Air Flow
G3 G4 Primary Pocket Air Filter Washable Synthetic Media High Air Flow
G3 G4 Primary Pocket Air Filter Washable Synthetic Media High Air Flow
Specifications
Brand Name :
XNGK
Model Number :
XN-M5
Certification :
CE/ROHS
Place of Origin :
China
MOQ :
1pcs
Price :
negotiation
Payment Terms :
T/T or western Union or LC
Supply Ability :
3,000pcs per month
Delivery Time :
10-20 working days according to the QTY
Packaging Details :
Plastic bag inside, carton box outside, wooden case if required
Product Name :
G4 Primary Pocket Air Filter
Application :
Primary Filter
Filter efficiency :
G3 G4
Frame :
AL alloy
Size :
Standard or Customized
Feature :
Good performance
Sealant :
Sealed by ultrasonic
Gasket :
Neoprene if required
Final pressure drop :
450Pa
Environment :
80℃
Description

G3 G4 Primary Pocket Air Filter Washable Synthetic Media High Air Flow

Description:

This pocket filter is primary efficiency, filter media is pre filter non woven fibre cloth 5mm thickness washable;

Filter frame is aluminum alloy;

This kind of primary pocket filter can give a very good performance to fitler large particles as big as 5 micron;

Filter efficiency arrestance: 90-95 %;

Technical parameters:

Dimension Efficiency

Air flow rate / Initial pressure drop

( m3/h / Pa )

 Pockets

Media area

( m2)
295*595*500mm G4 1800 / 50 3 2.1
395*595*500mm G4 2400 / 50 4 2.9
495*595*500mm G4 3000 / 50 5 3.6
595*595*500mm G4 3600 / 50 6 4.8

Pressure drop range: ±15%

According to clients` requirements offer different specifications

Applications:

Pre filter ventilation system for public building such as school, food factory, Lab, hospital, medicine factory and so on;

Features:

The filter media can be wash 1 - 2 times before drop it, save budget; filter air flow rate can be changeable accroding to clients` requirements, pockets qantity determain the air flow rate;

All filter media sealed by ultrasonic machine ensure no air by pass;
