Knife Edge Water Resistant Hepa ULPA Air Filter FiberGlass Media Neoprene Gasket
Knife Edge Water Resistant Hepa ULPA Air Filter FiberGlass Media Neoprene Gasket
Specifications
Brand Name :
XNGK
Model Number :
XN-UP
Certification :
ISO
Place of Origin :
China
MOQ :
1 sets
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
1000 Sets per month
Delivery Time :
10-15 working days
Packaging Details :
plastic bag inside, carton box outside, wooden case reinforced
Frame :
Aluminum Alloy
Size :
Customized
Filter media :
HV glass fiber
Sealant :
Polyurethane
Gasket :
Neoprene
Faceguard :
Painted Metal Mesh
Description

Knife Edge ULPA Filter U15 99.999% EN:1822 MPPS @0.12 um Glass Fiber Media

The knife edge ULPA filters are mainly used for liquid gel seal ceiling grid system. The liquid gel seal can make sure high level filtration air tight.

The knife edge ULPA filters consist of anodized aluminum frame, HV company glass fiber efficiency U15 99.999% or U16, U17. Polyurethane glue as the sealant be installed into 4 direction of the anodized alu frame slots. The glue connect with filter pack perfectly so normally there is no leakage. Of course we will test every ULPA filters before pack them by laser particle counter according to MPPS 1822 standard.

The knife edge ULPA filter can be size customized. Standard thickness is 70, 90, 135mm. The thickness is the full thickness of frame include knife edge.

Knife edge design ULPA filters normally applied for high strict cleanroom, for example pharmaceutical or laboratories; unclear and other industries.

Specifications:

Filter media: glass fiber HV company

Frame: aluminum alloy;

Efficiency: U15 EN:1822 99.999% MPPS @ 0.12um

Size: customized;

Faceguard: coated metal mesh;

Sealant: polyurethane;

Gasket: dove tailed neoprene;

OEM: available;
