Flange Carbon Hepa Filter Single / Double Header , HV Glass Fiber Media Small Hepa H12 Filter
Flange Carbon Hepa Filter Single / Double Header , HV Glass Fiber Media Small Hepa H12 Filter
Flange Carbon Hepa Filter Single / Double Header , HV Glass Fiber Media Small Hepa H12 Filter
Flange Carbon Hepa Filter Single / Double Header , HV Glass Fiber Media Small Hepa H12 Filter
Specifications
Brand Name :
XNGK
Model Number :
XN-HE4
Certification :
CE ROHS
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
Western Union, T/T
Delivery Time :
10 - 20 working days
Packaging Details :
Plastic bag inside, carton box outside, wooden case if required
Frame :
SUS, Gal, Plywood
Filter media :
H13 Glassfiber media
Filter Efficiency :
Custom
Application :
Terminal air filtration
Service life :
3 - 4 years
Separator :
Hot melt glue
Gasket :
EVA / Neoprene
Description

Flange HEPA Filter Single or Double Header HV Glass Fiber Media

Technical Data

Size Efficiency Air Flow Resistance
610*610*292 mm F8 3600 m³/h 135 Pa
610*610*150 mm F8 1800 m³/h 135 Pa
610*610*292 mm H13 2000 m³/h 250 Pa
610*610*150 mm H13 1000 m³/h 250 Pa

Other size available;

Resistance ±15% around;

Features for flange HEPA filter:

1. HEPA filters with separators have very good advantageous, they are sophisticated designed, have better performance in rigorous situations;

2. The separator design can let air flow through easily, reducing pressure drop;

3. Stable efficiency for long time using;

4. Low resistance, large air filter area that make sure large dust holding ability;

5. Uniform air flow, long time service life;

Applications for flange HEPA filter:

  1. Cleanrooms HVAC terminal filtration for commercial & industrial buildings;
  2. For micron electrical, pharmaceutical, hospital, food industries ventilation system terminal filtration;
  3. Ventilation systems that with high temperature environments, or has high requirements for fireproof;

Performance:

  1. The Rigid Cell HEPA filters have large range efficiency like 99.97%, 99.99% @ 0.3 um, before leave the factory, all of the HEPA filters will be scanned by laser particle counter; All HEPA filters certified with mill certification;
  2. The glass fiber media separated by corrugated aluminum foil, that can reduce air pressure drop at the same time make full use of filter media in limited space; gasket can be provided for air inlet or outlet side, both side also available;
  3. Many kind of constructions for your choice, box type, double side header, singer header and so on;
  4. Frame choice, stainless steel, galvanized steel, AL board, plywood;
  5. The rigid cell HEPA filters can be used in clean rooms` HVAC system terminal filtration, reducing fine dust to required standard.
