PAO DOP Test Laminar Flow HEPA Filter Module For Pharmaceutical Cleanroom
PAO DOP Test Laminar Flow HEPA Filter Module For Pharmaceutical Cleanroom
PAO DOP Test Laminar Flow HEPA Filter Module For Pharmaceutical Cleanroom
PAO DOP Test Laminar Flow HEPA Filter Module For Pharmaceutical Cleanroom
Specifications
Brand Name :
XNGK
Model Number :
XN-AD
Certification :
ISO
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
1000 Sets per month
Delivery Time :
10-15 working days
Packaging Details :
carton box , wooden case
Frame :
Stainless steel, painted steel, galvanized steel
Efficiency :
H13 or H14
Size :
Customized
Filter material :
Glass fiber HV
Seal :
Gel Seal or Neoprene
Air flow rate :
500-4000CMH customized
Description

PAO DOP Test Laminar Flow Terminal HEPA Diffuser for Pharmaceutical Cleanroom

The PAO DOP laminar flow terminal HEPA diffuser consist of ducted steel housing and HEPA filter.

The HEPA filter efficiency is H13, H14 U15 and so on. HEPA filter material HV glass fiber, good performance and large dust holding ability.

There are DAP DOP generate and tester inside the HEPA diffuser to test if it`s air tight and on leakage.

Introduction:

1. Frame: painted cold roll steel, easily to clean, strong construction.

2. Frame is connected by welded, welding seam was sealed by glue.

3. HV HEPA filter glass fiber, mini pleated design.

4. Gel seal gasket;

5. Perforated ducted cold roll steel panel.

6. Air inlet size: 250, 300, 350mm

7. Air volume control: butterfly damper roomside adjustable.

8. PAO DOP test.

9. Options: knife edge HEPA, stainless steel frame;

Application:

The PAO DOP laminar flow terminal HEPA diffuser can be used in GMP standard pharmaceutical cleanroom. HEPA filters can be replaced on the roomside as well as the air flow volume.
