Drop Ball Impact Tester , Falling Weight Impact Test Machine
Drop Ball Impact Tester , Falling Weight Impact Test Machine
Drop Ball Impact Tester , Falling Weight Impact Test Machine
Drop Ball Impact Tester , Falling Weight Impact Test Machine
Drop Ball Impact Tester , Falling Weight Impact Test Machine
Drop Ball Impact Tester , Falling Weight Impact Test Machine
Drop Ball Impact Tester , Falling Weight Impact Test Machine
Drop Ball Impact Tester , Falling Weight Impact Test Machine
Drop Ball Impact Tester , Falling Weight Impact Test Machine
Drop Ball Impact Tester , Falling Weight Impact Test Machine
Specifications
Brand Name :
ASLi
Model Number :
AS-DB-200
Certification :
CE, ISO ,SGS
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
50 sets per month
Delivery Time :
15~20 workdays
Packaging Details :
Standard Export Plywood Case
Max. Height :
2m or assigned
Drop Method :
Free falling
Dimension W×H×D :
500×2110×500mm
Weight :
65Kg
Power :
AC220V
Rail :
According to customer’s requirement
Description

Drop Ball Impact Tester, Falling Weight Impact Test Machine

Applications:

Drop Ball Impact Tester, Falling Weight Impact Test Machine is used to measure the impact resistance by the specified steel ball at specified height. It applies for ceramic, acrylic, glass, plastic and etc.

Falling Weight Impact Test Machine Technical Parameters:

Model AS-DB-200
Max. Height 2m or assigned
Drop Method Free falling
Wight of Steel Ball

112,198,225,357,533,1042,2280g optional

Steel ball standard:JIS K-5400
Dimension W×H×D(mm) 500×2110×500
Weight (Kg) 65
Power AC220V
Rail According to customer’s requirement

Drop Ball Impact Tester , Falling Weight Impact Test Machine

Drop Ball Impact Tester Features:

1. Aluminium frame construction

2. Electromagnet

3. Foot Switch

Drop Ball Impact Tester , Falling Weight Impact Test Machine

Short introduction about ASLi factory:
We are a long history testing equipment manufacturer, in the past 28 years, we devoted to simulation environmental testing equipment and Mechannical vibration and shock testing machine. Drop Ball Impact Tester, Falling Weight Impact Test Machine is our star products , and we had obtained the CE certification for this machine .
