Circulating Drying Hot Air Industrial Oven High Temperature 300deg C To 500deg C
Circulating Drying Hot Air Industrial Oven High Temperature 300deg C To 500deg C
Circulating Drying Hot Air Industrial Oven High Temperature 300deg C To 500deg C
Circulating Drying Hot Air Industrial Oven High Temperature 300deg C To 500deg C
Circulating Drying Hot Air Industrial Oven High Temperature 300deg C To 500deg C
Circulating Drying Hot Air Industrial Oven High Temperature 300deg C To 500deg C
Specifications
Brand Name :
ASLi
Model Number :
RHD-60
Certification :
CE, ISO, SGS
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100 sets/ month
Delivery Time :
15 workdays
Packaging Details :
Standard Export Plywood Case
Internal Dimension :
W500×H600×D500mm
External Dimension :
W700×H1200×D650mm
Temperature Range :
RT~500℃
Indication Resolution of Temperature :
0.1℃ ( When temperature is 100℃)
Distribution Uniformity of Temperature :
±2.0℃ ( When temperature is 100℃)
Control Accuracy of Temperature :
±0.5℃
Control Method :
Micro PID+SSR+Timer
Storage Shelf :
Two layers
Description

300deg c to 500deg c Hot air circulating Drying high temperature hot air industrial oven

300deg c to 500deg c Hot air circulating Drying high temperature hot air industrial oven Application:
High Temperature Rubber Aging Oven, Two layers Accelerated Ageing Test Equipment are used to dry, bake and preheat various materials or specimen, by means of hot air circulation method to uniform the temperature distribution.

Circulating Drying Hot Air Industrial Oven High Temperature 300deg C To 500deg C

300deg c to 500deg c Hot air circulating Drying high temperature hot air industrial oven Technical Parameters:

Model RHD - 45 RHD - 60 RHD - 90 RHD - 120

Internal Dimension

W×H×D(mm )

 450×400×400 500×600×500 600×900×500 800×1200×700

External Dimension

W×H×D(mm )

 650×900×550 700×1200×650 850× 1600×700 1200× 1680×900

Interior and Exterior

Material

Interior material is SUS 304# stainless steel,

exterior is stainless steel or SEE cold-rolled steel with paint coated.
Temperature Range R.T. to 200; (300 to 500℃ is optional)

Indication Resolution/

Distribution Uniformity

of Temperature

 0.1℃/±2.0℃;( When temperature is 100℃)

Control Accuracy of

Temperature

 ±0.5℃;

Temperature Rising

Velocity

 Temperature rising velocity: from R.T. to 200℃,needs approx. 35mins
Control Method Micro PID+SSR+Timer
Storage Shelf Two layers
Viewing Window

When temperature is RT to 200℃ ,with viewing widow

When temperature is 200℃ to 500℃ ,without viewing widow
Power AC 220V 50/60HZ ; AC 380V 50/60HZ


300deg c to 500deg c Hot air circulating Drying high temperature hot air industrial oven Features:
1. Automatic temperature control with digital thermal-sensor
2. Excellent thermal insulation property of ovens wall, lower energy consumption,
3. Be able to pre-set temperature, digital temperature display with LED panel.
4. Temperature value flashes on indicator when reach preset value.
5. Circulation fan facility to keep even temperature and uniform heating

Circulating Drying Hot Air Industrial Oven High Temperature 300deg C To 500deg C

Material of Construction:
(1)Interior material is SUS#304 stainless steel
(2)Exterior material is paint coated steel plate
(3)Insulation Material of imported fire-proof rock wool
(4)Heating Medium: electric heating tube

Air circulating System:
(1)Fan Forced horizontal air circulation system;
(2)Temperature resistant special motor with long axis, and power 1/2 HP 50HZ
(3) Built-in adjustable wind guide plate.

Control System:
(1) P.I.D microcomputer automatic calculate temperature controller, PV/SV display at the same time, set by press key.;
(2) 220V Solid state relay temperature output;
(3) Current Controller : SSR no contact relay

Warranty: one year free warranty for whole set machine,lifelong time maintainance.


After-sale service: feedback within 8 hours after get the call or email.


Service:OEM service,Design service,Buyer lable service.


Certificate of these the machine:
China official 3rd party calibration report
CE certiification


For the package:
1. PP film first
2. Vacuum package
3. PP film again
4. 10mm thickness PU foam to avoid collision
5. stronged plywood case
6. Standard ASLI CASE MARK
