Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test
Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test
Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test
Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test
Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test
Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test
Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test
Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test
Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test
Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test
Specifications
Brand Name :
ASLI
Model Number :
F-TH-Volume(A-F)
Certification :
CE,TUV,ISO
Place of Origin :
DONGGUAN,CHINA
MOQ :
1 Set
Price :
Negotiation
Delivery Time :
30-35 work days
Packaging Details :
export standard plywood case
Temperature Range :
-70~+150℃
Humidity Range: :
20%~98%R.H.
Indication Resolution Of Temperature: :
0.1℃
Indication Resolution Of Humidity: :
0.1% R.H
Distribution Uniformity Of Temperature: :
±2.0℃
Distribution Uniformity Of Humidity: :
±3.0% R.H.
Description


Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test


Rapid rate temperature changing test chambers for lab test Application:

Fast Change Rate environmental test chamber, F-TH-408(A~F) Temperature Changing Chamber is used to test various types of materials for their tolerances of heat, cold, dry, humidity. It is applied for quality inspection for all types of electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries.

Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test

Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test

Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test

Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test​ technical parameters:

Model F-TH-150(A～F) F-TH-225(A～F) F-TH-408(A～F) F-TH-800(A～F) F-TH-1000(A～F)

Internal Dimension
W×H×D(mm)

 500×600×500 600×750×500 600×850×800 1000×1000×800 1000×1000×1000

External Dimension
W×H×D(mm)

 1750×2250×2350 1850×2350×2350 1850×2500×2750 2300×2750×2800 2350×2800×3000

Range of Fast
Temperature
Change

Temperature Range: -70℃ ～ 150℃；
Range of Fast Temperature Change: - 45 ～ +85℃ ；
Error Range of Fast Temperature Change : ±3.0℃ ;

Humidity Range
(Optional)

20% ～ 98%RH (10%-98% R.H. / 5%-98% R.H, is a special optional condition, need
Dehumidifier)
Temperature Rising/FallingSpeed Rate

The Temperature Rising/Falling Speed Rate with linear control : 5~30℃/min, adjustable
The Temperature Rising/Falling Speed Rate non-linear control : 5~30℃/min, adjustable
( A:5℃/min ; B:10℃/min ; C:15℃/min ; D:20℃/min ; E:25℃/min ; F:30℃/min )

Analytic Accuracy/
Distribution Uniformity
of Temperature and
Humidity

 0.1℃; 0.1% R.H/±2.0℃; ±3.0% R.H.

Control Accuracy of
Temperature and
Humidity

 ±0.5℃; ±2.5% R.H.
Situation of Test Load Non-load Situation(When the temperature rising and falling rapidly , humidity can not keep pace with the temperature)

Internal and External
Material

Material of the inner box is SUS 304# stainless steel,of the outer box is stainless steel or SEE
cold-rolled steel with paint coated.
Insulation Material

Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation
material
Cooling System Water cooling
Protection Devices

Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant
protection switch, over-humidity and over temperature protection switch, fuses, fault
warning system, water short storage warning protection
Optional Accessories Inner door with operation hole(Optional) , Recorder , Water Purifier, Dehumidifier
Compressor French Tecumseh Brand, Germany Bizer Brand
Power AC380V ； 3 ∮ 5lines ； 50/60HZ
Approx. Weight (Kg) 950 1250 1600 2000 2300



Inner door with operation hole (optional)
50mm or100mm Entrance hole for test wire, Dia.50mm or 100mm
Sample Shelves, two layers
RS-232 or RS-485 communication

Ess Fast Temperature Change Environmental Testing Equipment Climatic Rapid Rate Temperature Cycling Test​ features:
1. Graceful appearance, circularly shaped body, surface treated with mist strips. Easy to operate, safe and reliable.
2. Rectangular double-paned viewing window for observation of sample under test,with interior lights
3. Double-layer-insulated airtight doors, able to insulate the internal temperature effectively.
4. Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and automatically recyclable.
5. French Tecumseh is used as compressor, with environment friendly refrigeration R23,R404A
6. LCD display screen is used for the control unit, capable of displaying set point and actual point at the same time
7. The control unit has the functions of multiples segment program editing
8. Quick or ramp rates control of temperature and humidity.
9. Casters are provided for ease of mobility, with strong positioning screws.

Warranty: one year free warranty for whole set machine,lifelong time maintainance.

After-sale service: feedback within 8 hours after get the call or email.

Service:OEM service,Design service,Buyer lable service.
