6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table
6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table
6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table
6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table
6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table
6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table
6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table
6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table
6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table
6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table
Specifications
Brand Name :
ASLI
Model Number :
ES-6
Certification :
CE
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
500 sets per year
Delivery Time :
35-40 workdays
Packaging Details :
Standard export plywood case
Force :
6KN
Standard :
UN38.3 &UL1642
Frequency :
5~3000Hz
Rated Acceleration :
100g
Rated Speed :
1.8m/s
moving coil :
6.5kg
Description

6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table

Our advantages with electrodynamic shakers:


1.Professional technology support.
2.Full experience of large numbers containers loading in Chinese sea port.
3.Fast shipment by reputed shipping line.
4.Best service after shipment with emails.

Shaker Table With Horizontal Slip Table Technical Parameters

Model Rated Sine
Force (N)		 Rated Random
Force (N)		 Frequency
Range (Hz)		 Rated Acceleration (m/s2) Rated Speed(m/s) Rated displacement
(p-p)mm		 Max. Loading (Kg) moving coil(Kg) Dimension of
Moving coil(mm)
ES-1 1000 1000 3-3500 400 1.2 25 70 2.5 Φ150
ES-2 2000 2000 3-3500 800 1.6 25 70 2.5 Φ150
ES-2a 2000 2000 3-3500 300 1.6 40 70 8 Φ230
ES-3 3000 3000 3-3500 1000 1.6 25 100 3.5 Φ150
ES-3a 3000 3000 3-3500 400 1.6 40 120 9 Φ230
ES-6 6000 6000 3-3500 1000 1.6 25 180 6.5 Φ230
ES-6a 6000 6000 3-3500 1000 1.6 51 250 12 Φ230
ES-10 10000 10000 3-3000 1000 1.8 51 270 14 Φ240
ES-20 20000 20000 3-3000 1000 1.8 51 300 30 Φ320
ES-30 30000 30000 3-2800 1000 1.8 5l 450 40 Φ450
ES-40 40000 40000 3-2800 1000 1.8 51 500 50 Φ450
ES-50 50000 50000 3-2700 1000 1.8 51 750 50 Φ450
ES-60 60000 60000 3-2700 1000 1.8 51 750 60 Φ450
ES-100 100000 100000 3-2500 1000 1.8 51 1000 90 Φ450
ES-120 120000 120000 3-2200 1000 1.8 51 1100 90 Φ500
ES-160 160000 160000 3-2100 1000 1.8 51 1500 150 Φ600
ES-200 200000 200000 3-2000 1000 1.8 51 2500 200 Φ650
ES-350 350000 350000 3-1700 1000 1.8 51 4500 300 Φ870

technical parameters of horizontal expander:

6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table

Laboratory Vibration Test Equipment Vertical Vibration Test System Pictures
6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table

Package about electrodynamic vibration shaker:

PP film first, and then 10mm foam between machine and the case, and outside is standard export plywood case.

6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table

Short introduction about ASLi factory:


We are a long history testing equipment manufacturer, in the past 28 years, we devoted to simulation environmental testing equipment and Mechannical vibration and shock testing machine. UN38.3 Standard Electromagnetic High Frequency Vibration Testing Machine is our star products , and we had obtained the CE certification for this machine .

6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table

Exhibition:

6KN Electrodynamic Vibration Half Sine Wave Shock Testing Shaker With Horizontal Slip Table

If you have any inquiry about the high freqency vibration shock tester , pls contact with us freely . thank you .
