Specifications
Brand Name :
ASLI
Model Number :
TH-408-D
Certification :
CE, ISO , SGS
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiate
Payment Terms :
T/T, Western Union
Supply Ability :
50 sets per month
Delivery Time :
20 workdays
Packaging Details :
wooden case
Usage :
Temperature Humidity Test Chamber for Resisting Heat
Temperature range :
-40~+150℃
Humidity range :
20%~98%
Controller :
Programmable LCD touch screen
Accuracy/ uniformly :
±0.1 degree ±0.1%R.H./ ±1.0 degree ±3.0%R.H.
Heating / cooling time :
about 1.0/min(cool)
Warranty :
1 year
application :
Glass
Description

=click for details>>>>>>> Programmable Temperature Humidity Test Machine

Optional accessories:

Low Humi. Dehumidifying system

Inner glass door with manual operating ports

Temp. /Humi. automotic recoder

Pure water treatment device

RS-485 interface can be linked to personal computer and achieve mutil-level control and recorder software management

Liquid nitrogen(LN2)/ Liquid carbon dioxide(LCO2) fast cooling-down system

Technical Parameters of cloud chamber:

Model TH-80(A~F) TH-150(A~F) TH-225(A~F) TH-408(A~F) TH-800(A~F) TH-1000(A~F)

Internal Dimension

WxHxD (mm)

 400x500x400 500x600x500 600x750x500 600x850x800 1000x1000x800 1000x1000x1000
External Dimension WxHxD (cm) 950x1650x950 1050x1750x1050 1200x1900x1150 1200x1950x1350 1600x2000x1450 1600x2100x1450
Temperature Range

Low Temperature(A:25°C B:0°C C:-20°C D:-40°C E:-60°C F:-70°C)

High Temperature 150°C
Humidity Range 20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is optiona , need Dehumidifier)
Indication relolution/Distribution uniformity of temperature and humidity 0.1°C; 0.1% R.H/±2.0°C; ±3.0% R.H.
Indication relolution/Distribution uniformity of temperature and humidity ±0.5°C; ±2.5% R.H.
Temperature Rising / Falling Velocity Temperature rising approx. 0.1~3.0°C/min
temperature falling approx. 0.1~1.5°C/min;
( Falling Min.1.5°C/min is optional)
Inner and OuterMaterial Interior material is SUS 304# stainless steel, exterior is stainless steel or see cold-rolled steel with paint coated.
Insulation Material Resistant to high temperature, high density, formate chlorine, ethyl acetum foam insulation materials
Cooling System Wind cooling or water cooling, (single segment compressor-40°C, double segment compressor -70°C)
Protection Devices Fuse-free switch, overloading protection switch for compressor, high and low voltage coolant protection switch, over-humidity and over-temperature protection switch, fuses, fault warning system, water short storage warning protection
Optional Accessories Inner door with operation hole , Recorder, Water Purifier, Dehumidifier
Compressor French Tecumseh Brand, Germany Bizer Brand
Power AC220V 1 3 lines, 50/60HZ , AC380V 3 5 lines , 50/60HZ
Approx. Weight (Kg) 150 180 250 320 400 450

Application of cloud chamber:


Temperature humidity test chamber is used to test various types of materials for their tolerances of heat, cold, dry, humidity. It is applied for quality inspection for all types of electronic products, electric appliance, and products from communication, instrument, automobile, plastic, metal, food, chemical, building materials, medical and aerospace industries.

cloud chamber Features:


1. Graceful appearance, circularly shaped body, surface treated with mist strips and plane. Easy to operate, safe and reliable.
2. Rectangular double-paned viewing window for observation of sample under test,with interior lights
3. Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and automatically recyclable.
4. French Tecumseh is used as compressor, with environment friendly refrigeration R23, R404A
5. LCD display screen, capable of displaying set point and actual values at the same time
6. The control unit has the functions of multiples segment program editing, and of quick or ramp rates control of temperature.
7. Casters are provided for ease of mobility, with strong positioning screws.

Pictures for reference:

Humidity Dry Chamber / Temperature Humidity Test Chamber 1 Year Warranty

Humidity Dry Chamber / Temperature Humidity Test Chamber 1 Year Warranty
