2 - Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber
2 - Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber
2 - Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber
2 - Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber
2 - Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber
2 - Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber
Specifications
Brand Name :
AISILI
Model Number :
TS-150-C
Certification :
CE , BV , SGS
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
100 sets per year
Delivery Time :
40 workdays
Packaging Details :
Wooden Case
Internal Dimension :
W600xH500xD500mm
External Dimension :
W1600xH2000xD1700mm
Temperature Range :
-65~150C
Temperature Recovery Time :
Within 5 Mins
Software :
Chinese-English
Viewing Window :
350*450mm
Total Chamber :
Three-Chamber
Power Supply :
AC380V
Description

2-Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber Price

Two zone hot and cold thermal shock camera with basket lifter (-60c to 150c) is used to test the bearing extent of the material structures and composite material in an instant and continuous high temperature and extremely low temperature environment, which is in the shortest time to test its thermal expansion and contraction caused by chemical change or physical harm.

The equipment is widely used in metal, plastic, rubber, electronics and other materials and it can be used as an important reference for improving product quality. It meets the standard of MTL, IEC, JIS, GJB…

2-Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber Price Technical Parameters
Model TS-150(A~C)
Internal Dimension WxHxD (mm) 600x500x500
External Dimension WxHxD (mm) 1600x2000x1700
Temperature Range of Testing zone

Type A:-40 °C~+150°C

( 200°C is Optional)

Type B:-55°C ~+150°C

( 200°C is Optional )

Type C:-65°C ~+150°C

( 200°C is Optional)

High temperature Range of Testing zone: +60ºC~+150ºC ( 200ºC is Optional);

Low Temperature Range of Testing Zone: -10ºC~-40ºC / -55ºC / -65ºC
Exposure Time of High/Low Temperature Exposure Time of High Temperature: +60°C ~ +150°C (200°C is Optional) 30Mins
Exposure Time of Low Temperature : -10°C~Type A:-40°C / Type B -55°C / Type C -65°C 30Mins
Temperature of Heat-Storing Slot / Heating Time RT~200°C/About 45mins
Temperature of Cool-storing Slot / Cooling Time RT~-75°C/ About 100mins
Temperature Recovery Time / Conversion Time ≤5min/≤5sec
Control Accuracy / Distribution Uniformity ±0.5°C/±2°C
Internal and External Material Material of the inner box is SUS 304# stainless steel,of the outer box is stainless steel or see cold-rolled steel with paint coated.
Insulation Material High temperature resistant , high density , formate chlorine , ethyl acetum foam insulation materials
Mechanics P.I.D+S.S.R+ Micro-computer balanced temperature control system
Cooling System Semi-hermetic double-stage compressor(water-cooled type) /Hermetic double-stage compressor (air-cooled type)
Security Protection Devices Non-fuse breaker, high and low pressure protective switch of the compressor , refrigerator high-pressure protective switch , failure warning system, electronic alarm
Accessories viewing window(special order)
Compressor French 'Tecumseh' Brand, Germany Bizer Brand
Power AC380V 3 ph 5 lines ,50/60HZ
Weight (Approx) 750 Kg

2-Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber Price Pictures
2 - Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber2 - Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber2 - Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber

2-Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber Price Features:


1. Perfect appearance and easy to operate.
2. Taiwan LCD display touch screen English-Chinese controller, with high memory capacity, can save 100 programs, max 9999 cycles, each cycle max time 999hrs.
3. Three chamber structures, high temperature chamber, low temperature chamber and test chamber, control automatically, stay and switch time adjustable.
4. Perfect protection alarm functions: short-circuits, Leakage, over temperature of work chamber; compressor over pressure, over load, short water…
5. Control interface will display alarm reason and provide check methods, machine has emergency stop button.
6. Cold and hot shock temperature recover within 5 minutes, which complies with MTL, IEC, JIS, GJB and other international standards.
7. With RS-232 communication port for connecting PC to control, record and save test report.

Packaging & Shipping

Package: PP film first, and then 10mm foam between machine and the case, and outside is standard export plywood case.

2 - Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber

Our service:


1.High quality guarantee.
2.Shipment with professional documents.
3.Packing as your request, with photo before shipment.
4.Reply within 48 hours and provide solution within 3 working days
5.Professional after-service from our engineers.
6.Warranty period 12 monthes.


Our advantages:


1.Professional technology support.
2.Full experience of large numbers containers loading in Chinese sea port.
3.Fast shipment by reputed shipping line.
4.Best service after shipment with emails.
5.We are professional test equipment manufaturer in China with excellent experience and skills, also have best quality products


Our concept:


1.Client is first. We are trying to bring maximum profit to our clients and offer best quality products
2.Credibility is the most important.
3.Quality control is our life.
4.Great sense of responsibility.

Customers' Visit ASLi Factory:

2 - Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber

Certifications

2 - Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber

Customer Reference List:

2 - Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber

Company Information

We are a long history testing equipment manufacturer, in the past 28 years, we devoted to simulation environmental testing equipment and Mechannical vibration and shock testing machine.Three-Chamber Thermal Shock Test System/Thermal Shock Chamber is our star products , and we had obtained the CE certification for this machine .

Exhibition:

2 - Zone Temperature Thermal Shock Cycling Test Equipment Machine Chamber

FAQ

1. Are your company a trading one or a factory?

Factory ,28 years focusing on test instruments field,4 years exporting experience.

2. After an order is placed, when to deliver?

Generally about 20 days, If we have finished products, we can arrange shipment within 3 days.

Please be aware that our production lead times depend on specific items and item quantities.

3. What about the warranty with after - sales services?

12 months warranty.

After the warranty, the professional after-sale service team will provide perfect technical support,and help customer solve problems encountered while using our product, handles guest problems and complaints in a professional and timely.

4. What about the services and product' quality?

Each instruments must be carried out 100% quality examination and test, the finished products must through a third party calibration institutions before shipping and delivery goods.

5. How to install and training?

5-1. If the products is easy to install and training, customers can learn the operation and maintenance manual to installation and use.

5-2. If the products is hard to use, customers can come ASLi factory to learn how to installation and use. And our engineers have a passport, we can go to overseas.
