Battery / Mobile phone/ Electronic Products Pneumatic Drop Test Machine

Application:

This machine is suitable for free fall test of mobile phone (mobile phone), walkie-talkie, electronic dictionary, building intercom, charger, power supply, CD/MD/MP3 and other small consumer electronic products and parts.

Feature:

The machine adopts pneumatic structure, and the tested parts will be clamped in a special fixture (adjustable stroke), press the down and down button, the cylinder will be released, and the test pieces will be tested in free fall.Drop height can be adjusted up and down, with a height scale, the drop height can be known.A variety of drop floor can be selected to meet different test standards.

Meet Standard:

JIS C 0044 IEC 60068-2-32

Main Parameter:

1. Maximum Load: 5 Kg

2. Effective drop height: 300~1500mm

3. Drop height indication: 1cm

4. Drop height display: LED meter digital display

5. Maximum Dimension of Sample: 300*400mm

6. Drop floor : steel plate

7. Drop mode: edge, corner, face all-round drop

8. Transmission mode: electric lifting, pneumatic drop

7. Base plate size: 500x600x20mm

8. Use air pressure: <1Mpa

9. Machine size (approx.): W700 x D900 x H2200mm

10. Machine weight: 80kg

11. Power source: 1 phase, 220V, 5A

Features of dop testing equipment :

1. The cabinet is treated with electrostatic baking varnish, the whole machine is designed reasonably, the operation is safe, stable, accurate and beautiful;

2, pneumatic clamping products, the front end of the fixture is equipped with silicone rubber, so that the product is not easy to deform;

3, test height electric lifting mode, high-precision instrument indicating test height;

4, equipped with a protective box, can prevent the product from falling out of the outside

• Pneumatic clamp sample

If you need more information about Battery / Mobile phone/ Electronic Products Pneumatic Drop Test Machine, please feel free to send your inquiry.
