R404A 22.5L Benchtop Temperature Chamber For Electronic Programmable
R404A 22.5L Benchtop Temperature Chamber For Electronic Programmable
Specifications
Brand Name :
SANWOOD
Model Number :
SM-22-CC
Certification :
CE AND ISO
Place of Origin :
China
MOQ :
1
Price :
Up to quantity
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
60 sets per month
Delivery Time :
30 working days
Packaging Details :
Strong Wooden Case Package, meet the long term shipment requirement
Controller :
Touch Screen, programmable
Volume :
22.5L
Highest Temperature :
150C
Lowest Temperature :
-40C
Function :
High Low Temperature simulate
Refrigerant :
R404A, R23 or R449A
Description

22.5L Benchtop Climatic Chamber For Electronic Devices Reliability Test

22.5L Benchtop climatic chamber SM-22-CC is applied to test the materials in heat-resistance, cold-resistance, dry-resistance, high low temperature cyclic tests, etc. It is simple to operate and easy to edit the test programs. It can show the set values and operative time.

Applied to verification and validation the products quality, such as electronic, plastic products, electrical appliances, instruments, food, vehicles, metals, chemicals, building materials, aerospace, medical care and so on.

Equipment performance
Name Benchtop Temperature Test Chamber
Model SM-22-CC
Inner dimension 300x300x250mm ( W x H x D )
Inner volume 22.5L
Outer dimension 480x835x990mm ( W x H x D )
Temperature Range -40℃～150℃
Heating Rate 3.0℃~5.0℃/min
Cooling rate 0.7℃~1.5℃/min
Temperature fluctuation ±0.5℃

Mechanical structure design
1-1. Internal material Cold resistance and heat resistance1.2mm stainless steel (SUS #304) plate fully welded
1-2. External material 1.5mm A3 steel plate galvanized and paint
1-2. Main structure design The Sheet metal area, Circuit area, Refrigeration zone, three parts.
1-3. Heat/Cold storage material Aluminum alloy have large capacity to storage heat and cold energy
1-4. Observation window Multi - layer insulating glass observation window with energy-saving LED lighting source
1-5.Sample rack bearing capacity No more than 20 kg/ each layer
1-6. Sample rack moving mode The sample rack is movable and height adjustable
1-7.Sample Rack

2 stainless steel self
1-8.Insulation layer Heat insulation layer flame retardant PU+Heat insulation glass wool(100mm Insulation layer)
1-9. Equipment movement and fixation

Heavy duty casters with adjustable leveling feet

1-10. Accessories

Taiwan original rotatable handle

Japanese original imports #304 SUS hinge , which can prevent the box door shaking.

Energy-saving 18W LED lights built into the window for easy viewing without glare.

R404A 22.5L Benchtop Temperature Chamber For Electronic Programmable

How does an environmental chamber work?
Environmental chambers work on the principle that all conditions can be managed manually through various mechanical processes.

Temperature is controlled by electric heater heating or cooling unit cools the chamber.

For example, to simulate the corrosive effects of the ocean, the researchers sprayed a salt solution through nozzles in the chamber, creating a fine mist that covered the entire product.

Humidity in the test chamber can be simulated in two different ways: by evaporating water using a heat source or ultrasonic technology.
