SANWOOD 800L Environmental Chamber Programmable Remote Control to PC for Automotive Products Reliability Test
SANWOOD 800L Environmental Chamber Programmable Remote Control to PC for Automotive Products Reliability Test
SANWOOD 800L Environmental Chamber Programmable Remote Control to PC for Automotive Products Reliability Test
SANWOOD 800L Environmental Chamber Programmable Remote Control to PC for Automotive Products Reliability Test
SANWOOD 800L Environmental Chamber Programmable Remote Control to PC for Automotive Products Reliability Test
SANWOOD 800L Environmental Chamber Programmable Remote Control to PC for Automotive Products Reliability Test
Specifications
Brand Name :
SANWOOD
Model Number :
SMC-800-CC
Certification :
CE AND ISO
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
60 set per month
Delivery Time :
4-5 weeks
Packaging Details :
Wooden case
Temperatuer range: :
-40℃～180℃
Humidity range: :
10%RH～98.0%RH
Temperature fluctuation: :
±0.5℃
Cooling rate: :
1.0～3.0℃/min
Internal material :
SUS304 stainless steel(1.2mm)
External material :
Cold-rolled plate(1.2mm),powder coating
Description

SANWOOD 800L Environmental Chamber Programmable Remote Control to PC for Automotive Products Reliability Test

The constant temperature and humidity test chamber is widely used in scientific research, research institutes, quality inspection institutes and other industries to do warm and humid heat tests of electronic and electrical products, materials, parts, equipment, etc., alternating heat test and constant temperature test, etc. Also could do high and low temperature routine tests, low temperature storage, in order to evaluate the performance of the sample under given environmental conditions.

It's widely used for industries of Electronic and Electric, Equipment and Instrument, Plastics & Rubber, Construction, Communication, Research and institute, Energy and Laboratories, etc.

Product Overview:

SANWOOD 800L Environmental Chamber Programmable Remote Control to PC for Automotive Products Reliability TestSANWOOD 800L Environmental Chamber Programmable Remote Control to PC for Automotive Products Reliability Test

Sanwood temperature and humidity test chamber technical parameter:

Model SMC-800-CC
Temp. range

-40°C ～180°C

(can be CA: 0~ 180°C; CB -20°C ~ 180°C; CD -70°C~180°C)

Display resolution 0.1°C
Temperature stability High±0.5°C ,low ±1.0°C
Temperature uniformity ≤±2.0°C
Heating Rate -40°C ～+180°C, 3.0 ~ 5.0℃/min;
Cooling rate

180°C ～25°C cooling rate 2.0~3.0℃/min;

25°C ～-40°C cooling rate 1.0~2.0℃/min;
Humidity control range 10%RH ~ 98%RH
Interior material Stainless Steel Plate ( SUS 304)
Exterior material A3 plate with power coating. Color can be customized
Insulation material Rigid polyurethane Foam and Glass Fiber Wool
Inner size (WxHxD) mm 1000x1000x800
External size (WxHxD) mm 1200x2050x1600
Ambient Temp. +5°C ～+35°C
Power supply 380V AC, 50Hz/60Hz 3 phase
Weight 720KG
Observation window size 450 X 450mm
Sample holder 2 pcs
Fittings cable port(portΦ100mm) x2
Safety device (standard) No fuse breaker,over pressure,over heat&over current protect,over temp. protect, over load protect for blower, dry heat protect
Control System Balanced Temperature & Humidity Control (BTHC)System
Refrigeration system Air Cooled (Water Cooled is option)
Hermetic compressor
Double stage refrigeration system,
R408 AND R23 (Option: R449A, R508)
Controller 5'7-inch LCD Touch Screen panel
Operation model :Program or fix point running
Memory capacity :120programs,1200steps,
All repeat 999 cycles, part repeat 99 cycles
