Specifications
Brand Name :
SANWOOD
Model Number :
SM-KS-1000-CC
Certification :
CE AND ISO
Place of Origin :
GUANGDONG,CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
60 set per month
Delivery Time :
4-6 weeks
Packaging Details :
Sanwood Standard Package (Wooden case suitable for sea, air and truck shipment)
Temperature impact range :
-70℃～180℃ （A:5℃/min ;B:10℃/min; C: 15℃/min; D:20℃/min)
Temperature fluctuation :
±1.0℃
Cooling rate :
155.0℃～-55.0℃ linear/non-linear 5.0 ~20.0℃/min
Heating rate :
-55.0℃~155.0℃ linear/non-linear 5.0 ~20.0℃/min
Compressor :
France Tecumseh, Germany Bock, Germany Bitzer
Humidity control :
10% ~95%RH
Description

Customized ESS Chamber

Rapid Temperature Change Test Chamber Temperature Resistance for Industries Products

Rapid Temperature Change Rate Test Chamber description

Sanwood Rapid temperature change rate test chamber, also name as environmental stress screen test chamber, ESS chamber, is to change the external environmental stress by using the temperature acceleration technique (the product produces alternating expansion and contraction when circulating in the upper and lower extreme temperatures) under the design strength limit, so as to generate thermal stress and strain in the product.

Rapid Temperature Change Rate Test Chamber is suitable for the whole product, parts and materials for high temperature, low temperature, high and low temperature cyclic and temperature stress screening (ESS) test, and constant humidity and cyclic damp heat test. Mainly applied for aviation, automobiles, home appliances, research and other fields, etc.


SANWOOD Rapid Temperature Change Rate Test Chamber / ESS chamber advantages:

1. Meet the requirements of stress screening test for electronic equipment at MIL-STD-2164, MIL-344A-4-16, MIL-2134A-19, NABMAT-9492, GJB-1032-90, GJB/Z34-5.1.6, IPC-9701....ETC.
2. Can perform a rapid temperature change (ESS), condensation test, high temperature and humidity test, temperature and humidity cycling test, etc.
3. Temperature change rate can be linear or non-linear two methods. Should specify when inquiry.
4. Can custom the stress screening (fast temperature change rate) at 5deg C/min, 10deg C/min, 15deg C/min experimental conditions
5. With aluminum sheet test machine load capacity (non plastic load);

6. Can screen the sample load with a large number

7. Built in two-way USB2.0 portable storage interface (can copy the test curve and load the test program)
8.Can be integrated with the E-management system to monitor the test, remote control to PC or APP.
9. Multi-language selection for controller: Chinese, English, Russian, Korean, Japanese, German multilingual language switching.

Environmental Stress Screening Chamber Ramp rate 15℃/min ESS chamber

SANWOOD Rapid Temperature Change Rate Test Chamber / ESS chamber technical specification:

Model SM-KS-1000-CC
Temperature Temperature control
range		 -70℃～180℃
Temperature fluctuation ±0.5℃
Cooling rate 125.0℃～-40.0℃ ( linear: 12.0℃/min)
Heating rate -40.0℃～125.0℃ ( linear: 12.0℃/min)
Temperature uniformity ±1.5℃ (-40.0℃～100.0℃)
±2.0℃ (100.1℃～180.0℃or-40.0℃～-70.0℃)
Humidity Humidity control range 10.0%RH～98.0%RH
Humidity fluctuation ±1.0% RH
Humidity uniformity ±2.0％RH
Material /
components		 Internal material Adopts 1.2mm thickness stainess steel(SUS304)
External material Adopts 1.5mm thickness Cold rolled steel sheet / powder spraying
Heat insulating material 100mm thickness polyurethane plate＋10mm thickness mineral wool
Fan Centrifugal blower
Compressor Semi-closed Germany Bock, Germany Bitzer
Condenser Air cooling or water cooling
Refrigerant R404A,R23,R508
Evaporator Fin - and - Tube Heat Exchanger
Heater Nickel chromium alloy heating wire
Humidifier Steam humidifier
Size Interior size(mm)
W*H*D		 1000x1000x1000
Volume(L) 1000L
Operating ambient temperature +5 ~ 35℃
Safety Adjustable over temperature protection, heater dry burning over temperature protection, humidifier dry burning, over temperature protection, automatic stop operation when troubles occur. Leakage protection function cuts off main power supply
Power supply 380V AC 50/60Hz
Controller Standard: Sanwood SH-5600 with Ethernet port
