High Precision IEC Standard AC 380V Gas Test Chamber Stainless Steel
High Precision IEC Standard AC 380V Gas Test Chamber Stainless Steel
High Precision IEC Standard AC 380V Gas Test Chamber Stainless Steel
High Precision IEC Standard AC 380V Gas Test Chamber Stainless Steel
High Precision IEC Standard AC 380V Gas Test Chamber Stainless Steel
High Precision IEC Standard AC 380V Gas Test Chamber Stainless Steel
High Precision IEC Standard AC 380V Gas Test Chamber Stainless Steel
High Precision IEC Standard AC 380V Gas Test Chamber Stainless Steel
Specifications
Brand Name :
Envsin
Model Number :
EQF
Certification :
ISO CE
Place of Origin :
Guangdong
MOQ :
1 set
Price :
$12000 >=1 Set
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
10 sets per month
Delivery Time :
35 work days
Warranty :
12 months
Power :
AC380v 50Hz/60Hz
Gas concentration :
5ppm~30ppm
Gas :
H2S,SO2,NO2,Cl2
Wind speed :
≤ 1.7m/s
Description
Product Overviews

25ppm NO2 SO2 Cl2 H2S Gas Corrosion Test Chamber

Our service:

•provide a comprehensive testing solution (customization)

•Preferential supplier of Apple , Huawei in China.

•Perfect systematic pre-sale and after-sale technical supports
Application:
Specification
Main Technical Parameters (Product Model:EQF)
Temp test
Temp range: 20℃~+45℃
Remark:
1. Test in accordance with IEC60068
under empty chamber condition (except indicated).
2. The test data of the water-cooled
test chamber are under the conditions that the water temperature is less than 28, the water pressure is from 0.3MPa to 0.6MPa, and the
water pressure difference between inlet and outlet is more than 0.2MPa.
Temp uniformity : ≤2.0℃
Temp deviation: ≤±2.0℃
Temp fluctuation: ≤±0.5℃
Temp rate:≥ 1℃/min
Temp and humidity test

Temp control range: 20℃~+50℃

Humidity range: 50% RH~85% RH
Humidity uniformity: ±5.0% RH
Humidity deviation: +2.0% ~ 3%RH( >75%RH)±5%R.H( ≤75%RH)
Humidity fluctuation: ±5.0%RH
Gas concentration 5ppm~30ppm
The deviation of gas concentration in the test chamber shall not exceed 10% of the set concentration,concentration uniformity deviation of 10%
The empty chamber operation meets the IEC60068-2-60 standard
Gas concentration measurement By calculating the volume ratio and then through the mass flowmeter measurement
On load capacity
500W,The temperature can be stable, the chamber body is not deformed
Noise
 Working noise ≤70dB ( measured at 1 meter away from the test chamber)
Gas flowmeter H2S,SO2,NO2,CI2
Standard

IEC60068-2-1:2007 Test A: Low temperature test method
IEC60068-2-2:2007 Test B: High temperature test method

IEC60068-2-78:2007 Test Cab: Constant humidity and heat test
IEC60068-2-30:2005 Test Db: alternating humidity and heat test
Quality Control
