Specifications
Brand Name :
Clion
Model Number :
CHA38S
Certification :
CE/CCC
Place of Origin :
China
MOQ :
500pcs
Price :
get latest price
Payment Terms :
T/T
Supply Ability :
2k pcs 7 days
Delivery Time :
7-14 days
Item NO. :
CHA38S-N/E/F
Shaft Diameter :
Ф6mm
Termination Mode :
G: Side Entry Cable
Working Power :
DC5-24V&Plusmn10 Percent
Specification :
Ф 38mm
Description

CHB-38S series Rotary Encoder

Features

1. Small size,Diverse varieties
2. Comprehensive functions
3. High-frequency response and resolution
4. Low power consumption
5. Stable and reliable performance

Ordering Informtaion

Clion CHA38S-N/E/F series Rotary Encoder with stable performance for motors, elevators,CNC machine tools

Specification

CHB38S series
Model CHA38S-N/E/F-(100,200, 360,400,600)
Main size External diameter:φ38mm; Shaft diameter:φ6mm
Working power DC5-24V±10%

Output mode		 N: Open-collector output (NPN)
E: Voltage output
F: Complementary output
Pulse output 100,200,360,400,600
Output phase A B
Termination mode G:Side entry cable
Application Bending machines, solar cutting machines, glass machinery and food packaging industry



Applications of the rotary encoder include pairing with our company's meter or rebar straightening machine, as well as various machinery industries such as textiles, packaging, printing, woodworking, plastics, etc., for counting and measuring displacement. It is widely used in automation control fields such as motors, elevators, CNC machine tools, robots, as well as in aerospace, industrial assembly lines, lifting industry, wind power industry, and more.

Dimensions
Clion CHA38S-N/E/F series Rotary Encoder with stable performance for motors, elevators,CNC machine tools

Clion CHA38S-N/E/F series Rotary Encoder with stable performance for motors, elevators,CNC machine toolsClion CHA38S-N/E/F series Rotary Encoder with stable performance for motors, elevators,CNC machine toolsClion CHA38S-N/E/F series Rotary Encoder with stable performance for motors, elevators,CNC machine tools
