Compact Design NNG41 Series Solid State Relay with 6.2mm Thickness Socket
Compact Design NNG41 Series Solid State Relay with 6.2mm Thickness Socket
Compact Design NNG41 Series Solid State Relay with 6.2mm Thickness Socket
Compact Design NNG41 Series Solid State Relay with 6.2mm Thickness Socket
Compact Design NNG41 Series Solid State Relay with 6.2mm Thickness Socket
Compact Design NNG41 Series Solid State Relay with 6.2mm Thickness Socket
Compact Design NNG41 Series Solid State Relay with 6.2mm Thickness Socket
Compact Design NNG41 Series Solid State Relay with 6.2mm Thickness Socket
Specifications
Brand Name :
NNC
Model Number :
NNG41-1/032F-38 1-2A
Place of Origin :
China
MOQ :
1600pcs
Price :
USD 1.2-1.6
Payment Terms :
T/T, L/C
Supply Ability :
30k pcs 7 days
Delivery Time :
8-15days
Packaging Details :
carton packing
Size :
28*5*18.5mm
Contact load :
low current
Theory :
solid state relay
Load current :
1A 2A
Type :
slim PCB SSR
Weight :
approx. 28g
Input voltage :
032F: 3-32V DC
Output voltage :
06: 5-60VDC; (Only for DC output) 22: 24-240VAC; 38: 24-440VAC; (Only for AC output)
Description
NNG41 Series Solid State Relay
Compact Design NNG41 Series Solid State Relay with 6.2mm Thickness Socket
Compact Design NNG41 Series Solid State Relay with 6.2mm Thickness Socket
Features:
Slim PCB SSR
With 6.2mm thickness socket
AC/DC output,DC input
Bi-direction SCR for AC output
Bi-polar transistor for DC output
LED indicator
ORDERING INFORMATION
*Note: Not all combinations of current and voltage are available
NNG41 - 1 / 032F - 38 1A - D ***
1.NNG41 series:
2.Load power supply: 0: DC Output; 1: AC Output;
3.Control voltage: 032F: 3-32V DC Input;
4.Load voltage: 06: 5-60VDC; (Only for DC output) 22: 24-240VAC; 38: 24-440VAC; (Only for AC output)
5.Rated load current: 1-2A
6.Socket: D: With socket; Blank: Without socket(only for maintenance)
7.Special code: ***: Customer Special Requirement; Blank: Standard

Compact Design NNG41 Series Solid State Relay with 6.2mm Thickness Socket

Compact Design NNG41 Series Solid State Relay with 6.2mm Thickness Socket

Compact Design NNG41 Series Solid State Relay with 6.2mm Thickness Socket

Compact Design NNG41 Series Solid State Relay with 6.2mm Thickness Socket

Compact Design NNG41 Series Solid State Relay with 6.2mm Thickness Socket

Certificate

Certificate

Shipment & Packaging

Shipment & Packaging

Packing Outer Box Paper box(pcs) 1600
Dimension of the carton CTN 380×215×175mm
Weight 1pc Approximate:28G
1ctn G.W:15KG N.W:14KG

FAQ

FAQ

Q1: Are you Factory?
A1:Yes,we focus on relay and micro switch more than 13years.

Q2: How do you control the products' quality?
A2: Auto inspection machine and manual testing together before packing.

Q3: What's your payment term?
A3:We usually accept T/T(30% deposit,the balance before delivery.)

Q4: Would you accept to use our logo?
A4: If you have good quantity,we can make OEM for you.

Q5: Can I get a sample for reference?
A5: We provide free samples for testing,you only need to pay the express cost.

Q6: What is your delivery time?
A6: Usually it takes 20-35 working days for production.

Q7: What is your warranty time of the products?
A7: 12-24 months
