Small Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless Steel
Small Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless Steel
Small Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless Steel
Small Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless Steel
Small Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless Steel
Small Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless Steel
Small Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless Steel
Small Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless Steel
Small Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless Steel
Small Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless Steel
Small Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless Steel
Small Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless Steel
Specifications
Brand Name :
CLW
Model Number :
CLW50749
Certification :
CCC,ISO,BV,SGS
Place of Origin :
Suizhou,China
MOQ :
1 UNIT
Price :
negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
300 units per month
Delivery Time :
30-35days after received advance payments
Packaging Details :
Naked packing
name :
truck mounted road sweeper
Auxiliary engine :
ISUZU Brand
Fan :
Maintenance Free type
rear Warning :
yes
Vacuum Suction :
Behind The Tire
Brushes :
4 units
Operating Manual :
yes
Operating Video :
yes
Usage :
City Sanitation,street cleaing
Warranty :
1 year
Description

FOTON Stainless Steel Dust Cleaning Road Sweeper Truck For Highway and Airport

Product Description

This equipment is made from our company according to many years of road maintenance construction experience, and combined with the actual needs of customers.It is a kind of vacuuming equipment independently developed and produced for minor repair and maintenance construction of irrigation joints and pits.The utility model has the characteristics of simple operation, high dust absorption efficiency and continuous operation.Widely used in municipal, highway, national and provincial arterial road construction dust, particle recovery operations.

Chassis
Drive Model 4X2, Left hand drive
Vehicle Main Dimensions Dimensions(L x W x H)(mm) 6150*2100*2600
Wheel base (mm) 3360
Wheel track (front/rear) (mm) 1730/1590
Approach/Departure angle(°) 22/14
Weight in KGS Curb Weight (kg) 3600
Front/Rear axle loading(kg) 3000/5280
Max. driving speed(km/h) 99
Engine Model Cummins
Horse Power(HP) 140
Emission standard Euro IV
Gearbox 6 forwards & 1 reverse
Steering Gear Power steering, hydraulic steering with power assistance
Brakes Hydraulic oil brake
Tire 7.00-16 tire , 6 + 1(spare tire)
Upper & Equipment
Tank Garbage tank Tank material Stainless steel 304
Tank volume(cbm) 4.0 cbm
Water tank Tank material Stainless steel 304
Tank volume(cbm) 1.5 cbm
Operation detail Max. Operation ability(m2/h) 45000-90000㎡/h
Auxiliary engine Model ISUZU Brand 57KW
Quantity(No.) 1
Power(kw/HP) 57 /77
Sweeper Sweeper Brush Quantity(No.) 4
Max. Working width(mm) 2800mm
Vacuum Cleaner 1 Unit, Behind the tyre
Remarks 1. Rear LED pilot lamp
2. Self unloading box body
3. Power system: DC 24V
4. The color will be designed on basis of your requirements.
5. Rear sucking hose as per customer request

Details

Small Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless Steel

Small Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless Steel

Small Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless SteelSmall Street Cleaner Vehicle Road Sweeper Truck Mobile Cleaning Stainless Steel

Sales Service

① Pre-sales Service: Communicate with customers, analyze their needs.
② Sales Service: Provide professional technical solutions, recommend the right models accordingly.
③ After-sales Service: For different products, we can quote the EXW, FOB, CFR or CIF price accordingly.

FAQ

Q1: What kinds of Sweeper Truck products I can order from your company?

A: We can supply all kinds of sweeper trucks, Vacuum sweeper truck, High pressure road sweeper truck, Normal road sweeper etc.

Q2: What is your production standard of Sweeper Truck products? Whether your Mobile Advertisement Truck can export to USA, Canada and Europen countries?

A: Our CBU Sweeper Truck is produced as per China GB local standard; We can't export CBU Sweeper Truck to those countries, but we can export super structure to those market, we exported 50 units Sweeper Truck to USA market at the beginning of 2017.

Q3: Have you supplied to Sweeper Truck any renowned companies?

A: Our group company is a regular strategic partner of some big government department and waste treatment company. We have supplied many different type Sweeper Truck for them with different chassis brand.

Q4: What about warranty?
A: Equipment warranty is 12 months from the date on which the equipment is applied successfully into operation, or 13 months from the date on which the equipment has been delivered, whichever comes first.

Q5: Where is your factory? How far from Shanghai to your factory?
A: Our factory based in Suizhou city, Hubei province, China. Our overseas marketing office in Wuhan. From Shanghai to WUhan is only 2 hours by airplane. Warmly welcome you to visit us in near future!
