Specifications
Brand Name :
United Tech
Model Number :
wooded barrel shredder
Certification :
ISO9001:2008
Place of Origin :
Zibo City, China
MOQ :
1 set
Price :
Negotiation
Supply Ability :
6-15 sets per month
Delivery Time :
Confirmed with Clients
Packaging Details :
plywood package or according to client's requirements
website :
www.utshredder.com
application :
wooden drum, plywood package barrel, Package tube, wooden barrel, plywood drum, package barrel, fiber drum, cardboard barrel, fiber container, DTY pipe, POY pipe, FDY pipe, nylon tube, spandex tube, spandex-clad tubes, BOPP tube, PET tube, PVC pipe, BOPA p
shredder :
double shaft shredder
Description

Our double shaft shredder ( Zibo United Tech Machinery Co., Ltd. ) have a wide application in the scrap paper package recycling:

Applications including:

Paper tube, Package tube, wooden barrel, plywood drum, package barrel, fiber drum, cardboard barrel, fiber container, DTY pipe, POY pipe, FDY pipe, nylon tube, spandex tube, spandex-clad tubes, BOPP tube, PET tube, PVC pipe, BOPA pipe, CPP tube, agricultural plastic film package paper tube, plastic wrap paper tube, aluminium tube package tube, industrial paper package pipe, etc.

Zibo United Tech Machinery Co., Ltd.

wooded drum shredder/ plywood drum shredder/ wooded package barrel shredder, high efficiency with low noise

Double shaft shredder have been designed for a wide array of applications and industries, suitable for shredding solid material such as E-waste, metal, wood, plastic, scrap tires, packaging barrel. Pallets, etc. And particularly well suited to the size reduction of bulky or voluminous materials which could include contamination such as metals or stones. Depending on input material and the following process the shredded material can be used directly or go into the next step of size reduction. It can efficient to increase the bulk density and decrease the transportation cost. It is widely used in industry waste recycling, medical recycling, electronic recycling, pallet recycling, municipal solid waste recycling, plastic recycling, tire recycling, paper making industry, etc.

Double Shaft Shredder has two rotors built into the machine that rotate at low speeds, high torque and low noise. With the function of Siemens microcomputer control system, it is possible to control automatically start, stop. Automatic reverse sensors to protect the machine against over loading and jamming.

Model D2830 D2840 D2860 D2880 D3260
dimension L/W/H(mm) 1450x1060x1850 1590x1060x1850 2560x1060x1850 2820x1060x1850 2658x1366x1911
Cutting Chamber size C/D(mm) 300x470 400x470 600x480 800x480 610x580
Rotor Blade Diameter(mm) Φ280 Φ280 Φ280 Φ280 Φ320
Rotor Ratate Speed (r/min) 14.2 14.2 14.2 14.2 14.8
Rotor Blade Quantity (PCS) 15 20 20 20 15
Rotor Blade Thickness(mm) 20 20 30 40 40
Rotor Motor Power(KW) 7.5 5.5+5.5 7.5+7.5 11+11 15+15
Model D3280 D32100 D32120 D42100
dimension L/W/H(mm) 2930x1385x1927 2930x1385x1927 3416x1946x2275 3275x1946x2275
Cutting Chamber size C/D(mm) 890x580 1020x580 1213x736 1052x736
Rotor Blade Diameter(mm) Φ320 Φ320 Φ320 Φ430
Rotor Ratate Speed (r/min) 14.8 14.8 14.8 9.2
Rotor Blade Quantity (PCS) 22 25 30 20
Rotor Blade Thickness(mm) 40 40 40 50
Rotor Motor Power(KW) 18.5+18.5 22+22 30+30 30+30
Model D42120 D42150 D52120 D52160
dimension L/W/H(mm) 3416x1946x2275 3716x2234x2670 3716x2234x2670 4016x2234x2670
Cutting Chamber size C/D(mm) 1213x736 1224x948 1224x948 1624x948
Rotor Blade Diameter(mm) Φ430 Φ516 Φ516 Φ516
Rotor Ratate Speed (r/min) 8.2 8.2 9.2 9.21875
Rotor Blade Quantity (PCS) 24 30 20 20+10
Rotor Blade Thickness(mm) 50 50 60 60+40
Rotor Motor Power(KW) 37+37 45+45 45+45 55+55

Note:

1. The voltage about the power supply can be selected by the customer’s specific requirements.

2. The shredder capacity can be influenced by the material compostion and output size.

Zibo United Tech Machinery Co., Ltd.

wooded drum shredder/ plywood drum shredder/ wooded package barrel shredder, high efficiency with low noise

What about the quality of your products?

1. we have a special training for each worker.

2. we use China famous brand spare parts to cast the machine.

3. have a trial test run before delivery the machine out of the factory.


How about the shipping and package?

1. we arrange shipment usually according to your special requirements.

2. Usually plywood package. Or according to clients's requirements.

How to get a suitable machine?

1. what is the raw material

2. the dimension of the input material and outpout material

3. the capacity,and power condition.

Tell me those data, we can help you choose the Waste type Shredder for you.

Please feel free to contact me any time with any questions.

We are waiting for you!

Our service:

(1) Your inquiry related to our products or prices will be replied in 24hours.
(2) Our engineer will make machine placement chart according to client’s workshop chart
(3) We provide 12 months guarantee since the date of bill of loading. All products are passed strict test.
