Specifications
Brand Name :
United Tech
Model Number :
texile shredder
Place of Origin :
Zibo City, China
MOQ :
1 set
Delivery Time :
Confirmed with Clients
Packaging Details :
plywood package or according to client's requirements
Certification :
ISO9001:2008
Price :
Negotiation
Supply Ability :
6-15 sets per month
website :
www.utshredder.com
application :
Applications: textile, waste cloth and waste yarn, waste cotton clothing, cotton, chemical fiber, flax, leather, plastic film, paper, trademark, non-woven fabric, tire cord fabric, curtain, friction cord, etc.
shredder :
double shaf shredder
Description

Waste Textile Shredder Functions:
The effective rotor-stator cutting principle with sieve below for defining the size of material flakes. Zibo United Tech Machinery Co., Ltd. - The waste textile shredder can shred the clothes / textiles into small size, up to 10*10mm.
Waste Textile Shredder Applications:
Textile after shredded can be used for cleaning or as raw material for further recycling. In that case, approximately 93% of all textile waste diverted to recycling. Among this part, about 35% are successfully reclaimed with going out as used clothing, 33% as reprocessed fibers (filler in vehicle seats, upholstery, insulation, etc), 25% is converted to cloth wipes and the left 7% textile waste to landfill.

Zibo United Tech Machinery Co., Ltd.

Applications: textile, waste cloth and waste yarn, waste cotton clothing, cotton, chemical fiber, flax, leather, plastic film, paper, trademark, non-woven fabric, tire cord fabric, curtain, friction cord, etc.
Waste Textile Shredder Features:
1. Sturdy, Wear-resistant, Reliable
2. Renewable Cutters with Harden Alloy Steel
3. High Capacity, Lower Price
4. High Efficiency, Lower Noise

adhesive bonded fabric shredder / non-woven fabric shredder, cloth crusher, texitle recycling, waste fiber shredder

Double shaft shredder have been designed for a wide array of applications and industries, suitable for shredding solid material such as E-waste, metal, wood, plastic, scrap tires, packaging barrel. Pallets, etc. And particularly well suited to the size reduction of bulky or voluminous materials which could include contamination such as metals or stones. Depending on input material and the following process the shredded material can be used directly or go into the next step of size reduction. It can efficient to increase the bulk density and decrease the transportation cost. It is widely used in industry waste recycling, medical recycling, electronic recycling, pallet recycling, municipal solid waste recycling, plastic recycling, tire recycling, paper making industry, etc.

Double Shaft Shredder has two rotors built into the machine that rotate at low speeds, high torque and low noise. With the function of Siemens microcomputer control system, it is possible to control automatically start, stop. Automatic reverse sensors to protect the machine against over loading and jamming.

Mode D2830 D2840 D2860 D2880
dimension L/W/H(mm) 1450x1060x1850 1590x1060x1850 2560x1060x1850 2820x1060x1850
Cutting Chamber size C/D(mm) 300x470 400x470 600x480 800x480
Rotor Blade Diameter(mm) Φ280 Φ280 Φ280 Φ280
Rotor Ratate Speed (r/min) 14.2 14.2 14.2 14.2
Rotor Blade Quantity (PCS) 15 20 30 40
Rotor Blade Thickness(mm) 20 20 20 20
Rotor Motor Powder(KW) 7.5 7.5 5.5+5.5 7.5+7.5
Net Weight(KG) 1300 1450 2000 2200
Model D3260 D3280 D4280 D42100
dimension L/W/H(mm) 2658x1366x1911 2930x1385x1927 2940x1816x2270 3275x1946x2275
Cutting Chamber size C/D(mm) 610x580 890x580 890x736 1052x736
Rotor Blade Diameter(mm) Φ320 Φ320 Φ430 Φ430
Rotor Ratate Speed (r/min) 14.2 14.2 14.8 14.8
Rotor Blade Quantity (PCS) 20 22 22 26
Rotor Blade Thickness(mm) 30 40 40 40
Rotor Motor Powder(KW) 15 18.5 15+15 18.5+18.5
Net Weight(KG) 2200 2400 3700 4100
Model D42120 D52100 D52130 D52160
dimension L/W/H(mm) 3416x1946x2275 3334x1866x2670 3716x2234x2670 4016x2234x2670
Cutting Chamber size C/D(mm) 1213x736 984x948 1324x948 1624x948
Rotor Blade Diameter(mm) Φ430 Φ514 Φ514 Φ514
Rotor Ratate Speed (r/min) 14.8 11.8 11.8 11.8
Rotor Blade Quantity (PCS) 30 20 26 32
Rotor Blade Thickness(mm) 40 50 50 50
Rotor Motor Powder(KW) 22+22 30+30 37+37 45+45
Net Weight(KG) 4500 6500 8700 9200

Note:

1. The voltage about the power supply can be selected by the customer’s specific requirements.

2. The shredder capacity can be influenced by the material compostion and output size.

Zibo United Tech Machinery Co., Ltd.

What about the quality of your products?

1. we have a special training for each worker.

2. we use China famous brand spare parts to cast the machine.

3. have a trial test run before delivery the machine out of the factory.

How about the shipping and package?

1. we arrange shipment usually according to your special requirements.

2. Usually plywood package. Or according to clients's requirements.

How to get a suitable machine?

1. what is the raw material

2. the dimension of the input material and outpout material

3. the capacity,and power condition.

Tell me those data, we can help you choose the Waste type Shredder for you.

Please feel free to contact me any time with any questions.

We are waiting for you!

Our service:

(1) Your inquiry related to our products or prices will be replied in 24hours.
(2) Our engineer will make machine placement chart according to client’s workshop chart
(3) We provide 12 months guarantee since the date of bill of loading. All products are passed strict test.
