double shaft shredder-paper factory plastic waste, scrap plastic strip, plastic rope, plstic strap, packing belt crusher
double shaft shredder-paper factory plastic waste, scrap plastic strip, plastic rope, plstic strap, packing belt crusher
double shaft shredder-paper factory plastic waste, scrap plastic strip, plastic rope, plstic strap, packing belt crusher
double shaft shredder-paper factory plastic waste, scrap plastic strip, plastic rope, plstic strap, packing belt crusher
Specifications
Brand Name :
United Tech
Model Number :
Double Shaft Shredder
Certification :
ISO9001:2008
Place of Origin :
Zibo City, China
MOQ :
1 set
Delivery Time :
Confirmed with Clients
Packaging Details :
plywood package or according to client's requirements
Price :
Negotiation
Supply Ability :
6-15 sets per month
website :
www.utshredder.com
application :
paper factory plastic waste,bulky garbage,waste home appliances,medical waste,
shredder :
double shaft shredder
Description

Double shaft shredder also known as shear type shredder , shredder and through shear , extrusion can reduce the material size. The shreddering machine widely used in the waste plastic , waste rubber , wood and other waste.

Zibo United Tech Machinery Co., Ltd. has the technology which is more mature and more advanced design of biaxial crusher series, volume reduction processing provides reliable quality equipment for pre crushing, utilization of waste recycling in china.

Recommended for solid waste, household waste, garbage, and some specific scrap materials., the advantage about waste shredder in Zibo United Tech Machinery Co., Ltd. as follow,
-High-torque
-Low noise
-Low speed
-Cutter hard-facing
-High efficiency
-Auto-reverse
-Compact and robust design
-Low operating and maintenance costs

double shaft shredder-paper factory plastic waste, scrap plastic strip, plastic rope, plstic strap, packing belt crusher

Double shaft shredder have been designed for a wide array of applications and industries, suitable for shredding solid material such as E-waste, metal, wood, plastic, scrap tires, packaging barrel. Pallets, etc. And particularly well suited to the size reduction of bulky or voluminous materials which could include contamination such as metals or stones. Depending on input material and the following process the shredded material can be used directly or go into the next step of size reduction. It can efficient to increase the bulk density and decrease the transportation cost. It is widely used in industry waste recycling, medical recycling, electronic recycling, pallet recycling, municipal solid waste recycling, plastic recycling, tire recycling, paper making industry, etc.

We specialize in this crusher and environment-protection field many year. with best quality, best service and competitive price,

More service we can provide:

1. Customize & OEM is available.

2. Consumable parts for free distribution.

3. Our engineer are available to service oversea.

4. Professional Free Design

5. Respect clients; Devote ourselves to improving the total value

6. 12 months warranty

Model D2012 D1630 D2040 D2850 D2860 D2880 D2890
Cutting Chamber size C/D (mm) 435×130 325×300 435×400 580×500 580×600 580×800 580×900
Rotor Blade Diameter (mm) 200 160 200 285 285 285 285
Rotor Ratate Speed (r/min) 5-10 10-20 10-20 10-20 10-21 10-20 10-20
Rotor Blade Quantity (PCS) 3 20 20 20 20 26 30
Rotor Blade Thickness (mm) 40 15 20 25 30 30 30
Rotor Motor Power (KW) 1.5+1.5/3 3+3/5.5 4+4/7.5 5.5+5.5/11 7.5+7.5/15 11+11/22 15+15/30
Net Weight (kgs) 800 1000 1200 1650 1800 2500 2500
Model D3280 D32100 D35120 D35150 D35150 D40100 D40120 D40150 D40180
Cutting Chamber size C/D (mm) 650×800 650×1000 680×1200 680×1500 680×1500 825×1000 825×1200 825×1500 825×1800
Rotor Blade Diameter (mm) 320 320 350 350 350 400 400 400 400
Rotor Ratate Speed (r/min) 10-15 10-15 10-15 10-15 10-15 10-15 10-15 10-15 10-15
Rotor Blade Quantity (PCS) 20 25 30 38 38 20 24 30 36
Rotor Blade Thickness (mm) 40 40 40 40 40 50 50 50 50
Rotor Motor Power (KW) 15+15/30 18.5+18.5/37 22+22 22+22 30+30 30+30 37+37 45+45 55+55
Net Weight (kgs) 4000 5200 6000 6500 7000 8000 8000 10000 12000
Model D43120 D43150 D43180 D52120 D52150 D52180 D62140 D62180 D62210
Cutting Chamber size C/D (mm) 900×1200 900×1500 900×1800 1100×1200 1100×1500 1100×1800 1300×1400 1300×1820 1300×2100
Rotor Blade Diameter (mm) 430 430 430 520 520 520 620 620 620
Rotor Ratate Speed (r/min) 10-15 10-15 10-15 10-15 10-15 10-15 10-15 10-15 10-15
Rotor Blade Quantity (PCS) 24 30 36 20 30 30 20 26 30
Rotor Blade Thickness (mm) 50 50 50 60 50 60 70 70 70
Rotor Motor Power (KW) 45+45 55+55 75+75 75+75 75+75 75+75 90+90 90+90 90+90
Net Weight (kgs) 8500 11000 13500 12000 14000 16000 15000 20000 24000

Note:

1. The voltage about the power supply can be selected by the customer’s specific requirements.

2. The shredder capacity can be influenced by the material compostion and output size.
