Specifications
Place of Origin :
Zibo City, China
Brand Name :
United Tech
MOQ :
1 set
Packaging Details :
plywood package or according to client's requirements
Delivery Time :
Confirmed with Clients
Model Number :
tire shredder
Certification :
ISO9001:2008
Price :
Negotiation
Supply Ability :
6-15 sets per month
website :
www.utshredder.com
application :
tire
shredder :
double shaft shredder
Description

Tire Shredder/Tyre shredder machine/Tire recycling machine :

The Tire Shredder/Tyre shredder machine/Tire recycling machine have been designed for a wide array of applications and industries, suitable for shredding solid material such as car tire, truck tire, e-waste, metal, wood, plastic, scrap tires, packaging barrel, pallets, etc. Depending on input material and the following process the shredded material can be used directly or go into the next step of size reduction. It is widely used in industry waste recycling, medical recycling, electronic recycling, pallet recycling, municipal solid waste recycling, plastic recycling, tire recycling, papermaking industry and etc.
Zibo United Tech Machiner Co., Ltd. --- Tire Shredder/Tyre shredder machine/Tire recycling machine series has two rotors built into the machine that rotate at low speeds, high torque and low noise. Adopt microcomputer control system with function of start, stop, automatic reverse sensors to protect the machine against over loading and jamming.

Tire Shredder/Tyre shredder machine/Tire recycling machine Application:

The Tire Shredder/Tyre shredder machine/Tire recycling machine is suitable for crushing the big solid material like television, washing machine, shell of refrigerator, big size pipe, pipe fittings, forklift splint, tyres, packing barrel, vehicle body, aluminum, copper and steel less than 10mm.

Our service:

(1) Your inquiry related to our products or prices will be replied in 24hours.
(2) Our engineer will make machine placement chart according to client’s workshop chart
(3) We provide 12 months guarantee since the date of bill of loading. All products are passed strict test.

high quality rubber tire crusher / tire shredder / tire breaker / double shaft shredder/ low noise, high efficiency

high quality rubber tire crusher / tire shredder / tire breaker / double shaft shredder/ low noise, high efficiency

high quality rubber tire crusher / tire shredder / tire breaker / double shaft shredder/ low noise, high efficiency

Model D2830 D2840 D2860 D2880 D3260
dimension L/W/H(mm) 1450x1060x1850 1590x1060x1850 2560x1060x1850 2820x1060x1850 2658x1366x1911
Cutting Chamber size C/D(mm) 300x470 400x470 600x480 800x480 610x580
Rotor Blade Diameter(mm) Φ280 Φ280 Φ280 Φ280 Φ320
Rotor Ratate Speed (r/min) 14.2 14.2 14.2 14.2 14.8
Rotor Blade Quantity (PCS) 15 20 20 20 15
Rotor Blade Thickness(mm) 20 20 30 40 40
Rotor Motor Power(KW) 7.5 5.5+5.5 7.5+7.5 11+11 15+15
Model D3280 D32100 D32120 D42100
dimension L/W/H(mm) 2930x1385x1927 2930x1385x1927 3416x1946x2275 3275x1946x2275
Cutting Chamber size C/D(mm) 890x580 1020x580 1213x736 1052x736
Rotor Blade Diameter(mm) Φ320 Φ320 Φ320 Φ430
Rotor Ratate Speed (r/min) 14.8 14.8 14.8 9.2
Rotor Blade Quantity (PCS) 22 25 30 20
Rotor Blade Thickness(mm) 40 40 40 50
Rotor Motor Power(KW) 18.5+18.5 22+22 30+30 30+30
Model D42120 D42150 D52120 D52160
dimension L/W/H(mm) 3416x1946x2275 3716x2234x2670 3716x2234x2670 4016x2234x2670
Cutting Chamber size C/D(mm) 1213x736 1224x948 1224x948 1624x948
Rotor Blade Diameter(mm) Φ430 Φ516 Φ516 Φ516
Rotor Ratate Speed (r/min) 8.2 8.2 9.2 9.21875
Rotor Blade Quantity (PCS) 24 30 20 20+10
Rotor Blade Thickness(mm) 50 50 60 60+40
Rotor Motor Power(KW) 37+37 45+45 45+45 55+55

Note:

1. The voltage about the power supply can be selected by the customer’s specific requirements.

2. The shredder capacity can be influenced by the material compostion and output size.

Zibo United Tech Machinery Co., Ltd.

What about the quality of your products?

1. we have a special training for each worker.

2. we use China famous brand spare parts to cast the machine.

3. have a trial test run before delivery the machine out of the factory.

How about the shipping and package?

1. we arrange shipment usually according to your special requirements.

2. Usually plywood package. Or according to clients's requirements.

How to get a suitable machine?

1. what is the raw material

2. the dimension of the input material and outpout material

3. the capacity,and power condition.

Tell me those data, we can help you choose the Waste type Shredder for you.

Please feel free to contact me any time with any questions.

We are waiting for you!

Our service:

(1) Your inquiry related to our products or prices will be replied in 12hours.
(2) Our engineer will make machine placement chart according to client’s workshop chart
(3) We provide 12 months guarantee since the date of bill of loading. All products are passed strict test.
