Metal Shredder/Metal cans/ Waste iron shredder machine/Metal Scrap recycling machine :
The Metal Shredder/Metal Cans shredder machine/Iron Scrap recycling machine have been design for a wide array of applications and industries, suitable for shredding solid material such as metal,car tire, truck tire, e-waste, wood,plastic, scrap tires, packaging barrel, pallets, etc. Depending on input material and the following process the shredded material can be used directly or go into the next step of size reduction. It is widely used in industry waste recycling, medical recycling, electronic recycling, pallet recycling, municipal solid waste recycling, plastic recycling, tire recycling, papermaking industry and etc.
Zibo United Tech Machiner Co., Ltd. ---
Metal Shredder/Metal Cans shredder/Iron Scrap recycling machine series has two rotors built into the machine that rotate at low speeds, high torque and low noise. Adopt microcomputer control system with function of start, stop, automatic reverse sensors to protect the machine against over loading and jamming.
Our service:
(1) Your inquiry related to our products or prices will be replied in 24hours.
(2) Our engineer will make machine placement chart according to client’s workshop chart
(3) We provide 12 months guarantee since the date of bill of loading. All products are passed strict test.
Metal Shredder/Metal Cans shredder machine/Iron Scrap recycling machine Application:
The Metal Shredder / Mrtal Cans shredder machine/ Iron Scrap recycling machine is suitable for crushing the big solid material like iron can,paper tube, wood tube, fishing net, pipe fittings, forklift splint, tyres, packing barrel, vehicle body, aluminum, copper and steel less than 10mm.
Double shaft shredder have been designed for a wide array of applications and industries, suitable for shredding solid material such as E-waste, metal, wood, plastic, scrap tires, packaging barrel. Pallets, etc. And particularly well suited to the size reduction of bulky or voluminous materials which could include contamination such as metals or stones. Depending on input material and the following process the shredded material can be used directly or go into the next step of size reduction. It can efficient to increase the bulk density and decrease the transportation cost. It is widely used in industry waste recycling, medical recycling, electronic recycling, pallet recycling, municipal solid waste recycling, plastic recycling, tire recycling, paper making industry, etc.
Double Shaft Shredder has two rotors built into the machine that rotate at low speeds, high torque and low noise. With the function of Siemens microcomputer control system, it is possible to control automatically start, stop. Automatic reverse sensors to protect the machine against over loading and jamming.
Mode | D2830 | D2840 | D2860 | D2880 |
dimension L/W/H(mm) | 1450x1060x1850 | 1590x1060x1850 | 2560x1060x1850 | 2820x1060x1850 |
Cutting Chamber size C/D(mm) | 300x470 | 400x470 | 600x480 | 800x480 |
Rotor Blade Diameter(mm) | Φ280 | Φ280 | Φ280 | Φ280 |
Rotor Ratate Speed (r/min) | 14.2 | 14.2 | 14.2 | 14.2 |
Rotor Blade Quantity (PCS) | 15 | 20 | 30 | 40 |
Rotor Blade Thickness(mm) | 20 | 20 | 20 | 20 |
Rotor Motor Powder(KW) | 7.5 | 7.5 | 5.5+5.5 | 7.5+7.5 |
Net Weight(KG) | 1300 | 1450 | 2000 | 2200 |
|
|
|
|
|
Model | D3260 | D3280 | D4280 | D42100 |
dimension L/W/H(mm) | 2658x1366x1911 | 2930x1385x1927 | 2940x1816x2270 | 3275x1946x2275 |
Cutting Chamber size C/D(mm) | 610x580 | 890x580 | 890x736 | 1052x736 |
Rotor Blade Diameter(mm) | Φ320 | Φ320 | Φ430 | Φ430 |
Rotor Ratate Speed (r/min) | 14.2 | 14.2 | 14.8 | 14.8 |
Rotor Blade Quantity (PCS) | 20 | 22 | 22 | 26 |
Rotor Blade Thickness(mm) | 30 | 40 | 40 | 40 |
Rotor Motor Powder(KW) | 15 | 18.5 | 15+15 | 18.5+18.5 |
Net Weight(KG) | 2200 | 2400 | 3700 | 4100 |
|
|
|
|
|
Model | D42120 | D52100 | D52130 | D52160 |
dimension L/W/H(mm) | 3416x1946x2275 | 3334x1866x2670 | 3716x2234x2670 | 4016x2234x2670 |
Cutting Chamber size C/D(mm) | 1213x736 | 984x948 | 1324x948 | 1624x948 |
Rotor Blade Diameter(mm) | Φ430 | Φ514 | Φ514 | Φ514 |
Rotor Ratate Speed (r/min) | 14.8 | 11.8 | 11.8 | 11.8 |
Rotor Blade Quantity (PCS) | 30 | 20 | 26 | 32 |
Rotor Blade Thickness(mm) | 40 | 50 | 50 | 50 |
Rotor Motor Powder(KW) | 22+22 | 30+30 | 37+37 | 45+45 |
Net Weight(KG) | 4500 | 6500 | 8700 | 9200 |
