Specifications
Brand Name :
YUAN
Model Number :
1000W
Certification :
CE,ISO,UV
Place of Origin :
China
MOQ :
1 set
Price :
6000-10000USD
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
50 sets
Delivery Time :
25 days
Packaging Details :
wooden box
Name :
CNC Fiber Laser Welding Machine
Model :
1000W
Usage :
Metal Welding
Laser Source :
IPG/Raycus/JPT
Adjustable powe :
5%-95%
Output fiber length :
5/10/15 m
Description

CNC Fiber Laser Welding Machine 1000W,1500W 2000W for Mild Steel ,Stainless Steel

Brief introduction:

The fiber continuous welding machine is a high-end,new type of welding method.It is

generally composed of a"welding host" and a "welding table",it adopt fiber laser device as the laser

generator,whole machine free of maintenance,no consumables,strong welding effect and more fibe weld seam.

It can meet the neess of users in different industries according to the matching shape and workbench on the

production site and the automation work widely used for seam welding ,stainless steel ,alloy,brass,galvanized sheet

high precision welding.

Application:

It can weld a wide range of metal,including the stainless steel,carbon steel,copper,aluminum,galvanized plate ,etc.

Widely applied in the fileds of aeronautical and space,mechanism,electron,communication,dynamic ,chemical ,automobile

manufactuer and other industries.

Parameters:

Model 1000/1500/2000W
Laser power 1000/1500/2000W
Laser wavelength 1080+-5nm
Beam quality
1.3m²
Work patterns Continuous
Power required AC220V / 380V
Output fiber length 5/10/15m (Optional)
Cooling method Water Cooling
Cooling water temperature 5-45℃
Average consumed power 2500/2800/3500/4000W
Laser Energy Stability <2%
Air humidity 10-90%

380V IPG CNC Fiber Laser Welding Machine For Stainless Steel 1000W 1500W 2000W380V IPG CNC Fiber Laser Welding Machine For Stainless Steel 1000W 1500W 2000W380V IPG CNC Fiber Laser Welding Machine For Stainless Steel 1000W 1500W 2000W380V IPG CNC Fiber Laser Welding Machine For Stainless Steel 1000W 1500W 2000W

Advantage:

1. Fast welding speed, 2~10 times faster than traditional welding.

2. Easy operating need no training

3. welding seam beautiful smooth and beautiful, don’t need polish, save your time.

4. No deformation or welding scar, firm welding of the workpiece.

5. Laser welding has less consumables and long service life.

6. Safer, more environmentally friendly.
