Name :
CNC Turret Punching Machine/Automatic Hole Punching Machine/CNC Punch Hydraulic Press Price
Return Force :
100 KN
Function :
Hole Pressing Machine
Nominal Force :
200kn/300kn/500kn
Description

CNC Turret Punching Machine/Automatic Hole Punching Machine/CNC Punch Hydraulic Press Price

The new generation of YUAN turret punch is a low energy, high efficiency turret punch with low environmental and maintenance costs. The YUAN can be configured in 22 or 33 ton options. The YUAN was designed with a thick turret to ensure longevity of the machine and its tools and to minimize tool deflection.YUAN performs full punches, hovering, marking and forming operations.The SF model can be upgraded with our Ultra Package which can decrease part processing times by up to 40%.
Feature:
Automatic Tool and Linear Components Lubrication System
Pneumatic Ball Transfer and Brush Table for ease of loading/unloading
Vacuum Assist System for slug removal
32 Stations 2 Auto indexing stations
One Mirror-Type Safety System to guard entire work envelope
Man-Sensors on moving tables
Sheet Jam Protectors to detect warped material
Sheet-gripper sensors to detect loose material
Components List
No.
Name
Brand
Gauge
1
CNC System
FANUC
Choose according to the X range
BECKHOFF
2
Servo Driver
FANUC or LT-i or
Choose according to the X range
BECKHOFF
3
Servo Motor
FANUC or LT-i or
Choose according to the X range
BRUSATORI
4
Guideway
THK
HSR35A6SSC0+4200L (X axis:2500)
HSR35A3SSC1+2060L-Ⅱ (Y axis: 1250)
HSR35A3SSC1+2310L-Ⅱ (Y axis: 1500)
5
Ballscrew
HIWIN
R32-25B1-FSV-1495-1735-0.012
(X,Y axis: 1250)
THK
BLK4040-3.6G0+3016LC7(X axis: 2500)
BLK3232-7.2ZZ+1735LC7T (Y axis:1250)
BLK3232-7.2ZZ+1985LC7T (Y axis: 1500)
6
Precise Bearing
NSK /Koyo
25TAC62BDFC10PN7B/SAC2562BDFMGP4Z
30TAC62BDFC10PN7B/SAC3062BDFMGP4Z
7
Coupling
KTR
GS2898ShA-GS2.5-φ24 2.5-φ24(X axis)
GS2898ShA-GS2.5-φ22 2.5-φ24(Y axis)
8
Pneumatic Parts
Three-joint
SMC
AC40A-06D
Solenoid valve
SY5120-5D-01
Muffler
AN10-01
Cylinder
CP96SDB40-80-A93L
9
Electrical System
Breaker
Schneider
/
Contact
Schneider
/
Approximate Switch
ELCO
/

Parameters:

Item
unit
P-30T
P-50T
Punching Capacity
Ton
30
50
X Traverse Length
mm
2500±10
2500±10
Y Traverse Length
mm
1250±10
2500±10
Max sheet size
mm
1250*5000
1250*5000
Max sheet Thickness
mm
6.35
8.35
Max sheet weight
kg
110
160
X Axis Traverse speed
m/min
120
100
Y Axis Traverse speed
m/min
105
80
Max Traverse speed
m/min
128
105
Punching speed at 25mm Pitch
Hist/min
450
380
Nibbling speed
Hist/min
1200
1050
Tools Type
Thick Turret
Max Punching Diameter
mm
88.9
Number of Tool Stations
32/42/52
Number of Auto Index Stations
Pcs(type)
4(2B+2C)/3(2B+C)/2(B+C)
Turret Rotating Speed
rpm
33
33
Auto Index Rotationg Speed
rpm
100
100
Ram Stroke Distance
mm
0~31
0~31
Working Tables Size
Brush+Supporting Ball Set
3
Number of Sheet Clamps
pcs
3
3
Air supply
NL/min
250
250
Air Pressure
6
6
Size of Control cabinet
1350*700*2185
CNC Controller
Fanuc Oi-PD
Number of Controllable Axes
4
Ram Memory
512
Serial Interface
PS232/RJ45/PCMCIA
Punching Precision
±0.1
Machine Dimension(L*W*H)
5940*5220*2420
5940*5220*2420
Net weight(approx.)
13500
15800
Product tags

cnc turret punching press

,

cnc turret punch press

,

cnc turret punching machine
