IPG Fiber Laser CNC Cutting Machine 1000W For 10mm Mild Steel
IPG Fiber Laser CNC Cutting Machine 1000W For 10mm Mild Steel
IPG Fiber Laser CNC Cutting Machine 1000W For 10mm Mild Steel
IPG Fiber Laser CNC Cutting Machine 1000W For 10mm Mild Steel
Specifications
Brand Name :
YUAN
Model Number :
1000W
Certification :
CE,ISO,UV
Place of Origin :
China
MOQ :
1 set
Price :
12000-69000USD
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
50 sets
Delivery Time :
25 days
Packaging Details :
wooden box
Laser Power :
1000W IPG Fiber Laser
Laser Souce :
Germany IPG Fiber Laser Resonator
Processing surface :
3000x1500 mm
CNC Control :
Shanghai FISCUT Cypcut
Laser Head :
Switzerland Raytools
Total electric power :
14 kw
Description

1000W IPG Fiber Laser CNC Cutting Machine for 10mm mils steel ,5mm stainless steel

General feature:

1.70% low electricity consumption in comparison with CO2 Laser.

2. Up to 300% fast cutting

3.High wall plug efficiency(>30%)

4.Flexible beam path

5.Maintenance free.

6.Copper,brass cutting ability

7.High output power

8.High optical quality

9.Compact size

10.Reliability

Standard Equipment:

1.IPG YLS-1000W Ytterbium laser resonator

2.Linear driven X,U and Y axes

3.High rigid frame

4.Empower or FAGOR CNC controller

5.Precitec cutting head

6.Lanteck software

7.Shuttle table

8.Chiller Unit

9.Proportional gas and pipe system

10.Dust filter

11.Compressor

12.Conveyor for scraps

Technical specification:

Laser power 1000W IPG Ytterbium Fiber Laser
Laser source Germany IPG fiber laser resonator
Processing surface(LxW) 3000x1500 mm
CNC control Shanghai FISCUT Cypcut
Laser head Switzerland Raytools
Power supply AC380V+-5% 50/60HZ(3 phrase)
Total electric power 14 KW
Position accuracy X,Y and Z axis +0.03 mm
Repeat position accuracy X,Y ,and Z aixs +0.02 mm
Maximum position speed of X and Y aixs 72m/min
Acceleration 1G
Max load of working table 1000 Kg
Drawing programming mode Al,DWG,PLT,DXF format import directly
machine weight 5T

Cutting Thickness Limit:

Article Name Cutting thickness limit
Carbon steel 12 mm
Stainless steel 6 mm
Aluminum 4 mm
Brass 3 mm
Copper 3 mm

Main Parts:

Article Remark
Fiber laser resonator IPG (Germany) 1000W
Servo motor DELTA (Taiwan)
Ball screw rod HIWIN(Taiwan)
Liner guide HIWIN(Taiwan)
Gear Rack YYC(Taiwan)
Laser head Raytools(Switzerland)
Chiller Tongfei(China)
Controller FISCUT(China)
Gas proportional valve SMC(Japan)
Reduction gear box APEX(Taiwan)
