Corrugated Sheet Roll Forming Machine Galvanized Steel / PPGI Steel / Galvalume Use
Corrugated Sheet Roll Forming Machine Galvanized Steel / PPGI Steel / Galvalume Use
Corrugated Sheet Roll Forming Machine Galvanized Steel / PPGI Steel / Galvalume Use
Corrugated Sheet Roll Forming Machine Galvanized Steel / PPGI Steel / Galvalume Use
Corrugated Sheet Roll Forming Machine Galvanized Steel / PPGI Steel / Galvalume Use
Corrugated Sheet Roll Forming Machine Galvanized Steel / PPGI Steel / Galvalume Use
Corrugated Sheet Roll Forming Machine Galvanized Steel / PPGI Steel / Galvalume Use
Corrugated Sheet Roll Forming Machine Galvanized Steel / PPGI Steel / Galvalume Use
Specifications
Brand Name :
Believe Industry Company
Model Number :
Corrugated Sheet Roll Forming Machine
Certification :
CE
Place of Origin :
CHINA
Payment Terms :
T/T, L/C
Delivery Time :
45 days
Packaging Details :
Standard Seaworthy Packing
Applicable Material :
PPGI Steel, Galvanized Steel, Galvalume Steel
Material Thickness :
0.1mm to 0.4mm
Main Power :
11KW
Forming Speed :
15-18m/min
Description

Galvanized Steel, PPGI Steel, Galvalume Corrugated Sheet Roll Forming Machine

Corrugated Sheet Roll Forming Machine Galvanized Steel / PPGI Steel / Galvalume Use Corrugated Sheet Roll Forming Machine Galvanized Steel / PPGI Steel / Galvalume Use

Corrugated Sheet Roll Forming Machine Galvanized Steel / PPGI Steel / Galvalume Use Corrugated Sheet Roll Forming Machine Galvanized Steel / PPGI Steel / Galvalume Use

Brief Introduction

This corrugated sheet roll forming machine can be used to produce corrugated sheets with material width from 762mm to 1250mm and material thickness from 0.1mm to 0.4mm. Main material are PPGI steel sheet, Galvanised steel sheet, Galvalume steel sheet.

Main Technical Parameters

1 Height Of Corrugations 15-20mm; can be manual adjust
2 Material Thickness 0.1-0.4mm
3 Material Width 1250mm, 1000mm, 914mm, 762mm
4 Applicable Material PPGI steel sheet, galvanised sheet, galvalume sheet
5 Diameter Of Shaft 140mm
6 Main Motor Power 11kw
7 Forming Speed 15-18m/min
8 Guiding Device Manual adjust type


Difference Between Two Types Of Corrugated Sheet Roll Forming Machine

Type & Difference

Corrugated Sheet Roll Forming Machine Galvanized Steel / PPGI Steel / Galvalume Use

Corrugated Sheet Roll Forming Machine Galvanized Steel / PPGI Steel / Galvalume Use
Material Thickness

0.1-0.4mm

 0.3-0.8mm
Process Cutting-->Feeding-->Roll Forming Feeding-->Roll Forming-->Cutting
