Metal Roof Tile Roll Forming Machine - YX16.8-200-800
Metal Roof Tile Roll Forming Machine - YX16.8-200-800
Specifications
Brand Name :
Beli
Model Number :
YX16.8-200-800
Place of Origin :
Wuxi, China
MOQ :
1
Price :
USD 30000-40000 / set
Payment Terms :
T/T, L/C
Supply Ability :
20 sets/ Month
Delivery Time :
45 days
Packaging Details :
Nude Packaging
Type :
Cold rolling machine
Condition :
New
Warranty :
18 months
Voltage :
380V, 3 phase, 50Hz
After-sales Service :
Enigineers available to service machinery overseas
Certification :
CE
Description

Description:

This Metal Roof Tile Roll Forming Machine can produce metal roof tiles. Main components of this machine are decoiler, guiding and leveling device, roll former, hydraulic cutting device, collecting table, hydraulic station, etc.

Technical Parameters - YX16.8-200-800
Raw Material Carbon Steel, Galvanized Steel, Q235
Material Thickness 0.3-0.8mm
Material Width Depend on specific profile
Diameter of Shaft 76mm
Material of Shaft 45# steel
Material of Rolls

45# steel Chromed with thickness 0.05mm
Main Power 7.5KW
Forming Speed 3-4m/min
Forming Station 18 stations
Cutting Type Hydraulic cutting
Cutting Blade

Cr12 Mov
