Solid Carbide End Mill with 2 Flute Accurate Arc Accuracy for Profile Milling

• Ideal for Partial Profiling, Corner and Arc Transition Plane Clearing & Milling.

Feature Advantage:

• Includes 2 edge mills and 4 edge mills.
• The minimum arc R0.1, the choice of various diameters and R values, meets a variety of processing requirements.
• It includes ball end mills for general occasions, high performance series, aluminum alloy series, high hardness series, etc. for various occasions.
• Ideal tool selection for partial profiling, cornering with arc transition plane clearing and milling.
• It is also a suitable choice for roughing the surface of rough parts.
• Due to the presence of the arc of the tool tip, the tool's anti-cracking ability is greatly improved, and the surface quality of the face milling process can be significantly improved.
• Precise tool arc accuracy ensures dimensional and precision requirements for machining.
• The integral alloy end mill can be reground and has the characteristics of repair and reuse, further reducing costs.
• Excellent dry cutting performance, whether dry or wet.

Base Material & Coating:

• Nano-grade coating for excellent wear resistance and high temperature stability.
• Ultra-fine particle cemented carbide substrate with excellent wear resistance.
• Advanced coating post-treatment technology combines with the substrate more tightly, with lower friction and better surface quality.

Chip-Breaker, Structure & Edge Treatment:

• Highly rigid tool structure design reduces tool vibration.
• The center of the ball with high strength and sharp edge is designed to properly handle the chips generated during cutting.
• The blade and the ball edge are seamlessly connected, and the ideal ball-edge center design greatly improves the surface quality.
• The production of high-precision five-axis CNC grinding machines guarantees the size, precision and surface quality of the tools.

Type (Part of the type):

Type	Handle Diameter (mm)	Total Length (mm)	Description
GM-2R-D1.0R0.2	4	50	2 Edges, Arc End Mill
GM-2R-D1.5R0.2	4	50	2 Edges, Arc End Mill
GM-2R-D10.0R0.5	10	75	2 Edges, Arc End Mill
GM-2R-D10.0R1.0	10	75	2 Edges, Arc End Mill
GM-2R-D10.0R1.5	10	75	2 Edges, Arc End Mill
GM-2R-D10.0R2.0	10	75	2 Edges, Arc End Mill
GM-2R-D12.0R0.5	12	75	2 Edges, Arc End Mill
GM-2R-D12.0R1.0	12	75	2 Edges, Arc End Mill
GM-2R-D12.0R1.5	12	75	2 Edges, Arc End Mill
GM-2R-D12.0R2.0	12	75	2 Edges, Arc End Mill
GM-2R-D2.0R0.2	4	50	2 Edges, Arc End Mill
GM-2R-D2.0R0.5	4	50	2 Edges, Arc End Mill
GM-2R-D2.5R0.2	4	50	2 Edges, Arc End Mill
GM-2R-D2.5R0.5	4	50	2 Edges, Arc End Mill
GM-2R-D3.0R0.2	4	50	2 Edges, Arc End Mill
GM-2R-D3.0R0.3	4	50	2 Edges, Arc End Mill
GM-2R-D3.0R0.5	4	50	2 Edges, Arc End Mill
GM-2R-D4.0R0.2	4	50	2 Edges, Arc End Mill
GM-2R-D4.0R0.3	4	50	2 Edges, Arc End Mill
GM-2R-D4.0R0.5	4	50	2 Edges, Arc End Mill
GM-2R-D4.0R1.0	4	50	2 Edges, Arc End Mill
GM-2R-D5.0R0.3	6	50	2 Edges, Arc End Mill
GM-2R-D5.0R0.5	6	50	2 Edges, Arc End Mill
GM-2R-D5.0R1.0	6	50	2 Edges, Arc End Mill
GM-2R-D6.0R0.3	6	50	2 Edges, Arc End Mill
GM-2R-D6.0R0.5	6	50	2 Edges, Arc End Mill
GM-2R-D6.0R1.0	6	50	2 Edges, Arc End Mill
GM-2R-D8.0R0.3	8	60	2 Edges, Arc End Mill
GM-2R-D8.0R0.5	8	60	2 Edges, Arc End Mill
GM-2R-D8.0R1.0	8	60	2 Edges, Arc End Mill
GM-4R-D10.0R0.5	10	75	4 Edges, Arc End Mill
GM-4R-D10.0R1.0	10	75	4 Edges, Arc End Mill
GM-4R-D10.0R2.0	10	75	4 Edges, Arc End Mill
GM-4R-D10.0R3.0	10	75	4 Edges, Arc End Mill
GM-4R-D12.0R0.5	12	75	4 Edges, Arc End Mill
GM-4R-D12.0R1.0	12	75	4 Edges, Arc End Mill
GM-4R-D12.0R2.0	12	75	4 Edges, Arc End Mill
GM-4R-D12.0R3.0	12	75	4 Edges, Arc End Mill
GM-4R-D3.0R0.2	4	50	4 Edges, Arc End Mill
GM-4R-D4.0R0.3	4	50	4 Edges, Arc End Mill
GM-4R-D4.0R0.5	4	50	4 Edges, Arc End Mill
GM-4R-D5.0R0.5	6	50	4 Edges, Arc End Mill
GM-4R-D5.0R1.0	6	50	4 Edges, Arc End Mill
GM-4R-D6.0R0.5	6	50	4 Edges, Arc End Mill
GM-4R-D6.0R1.0	6	50	4 Edges, Arc End Mill
GM-4R-D8.0R0.5	8	60	4 Edges, Arc End Mill
GM-4R-D8.0R1.0	8	60	4 Edges, Arc End Mill
PM-2R-D0.6R1.0	6	50	2 Edges, Arc End Mill
PM-2R-D1.0R0.2	4	50	2 Edges, Arc End Mill
PM-2R-D1.5R0.2	4	50	2 Edges, Arc End Mill
PM-2R-D10R0.5	10	75	2 Edges, Arc End Mill
PM-2R-D10R1.0	10	75	2 Edges, Arc End Mill
PM-2R-D10R1.5	10	75	2 Edges, Arc End Mill
PM-2R-D10R2.0	10	75	2 Edges, Arc End Mill
PM-2R-D12R0.5	12	75	2 Edges, Arc End Mill
PM-2R-D12R1.0	12	75	2 Edges, Arc End Mill
PM-2R-D12R1.5	12	75	2 Edges, Arc End Mill
PM-2R-D12R2.0	12	75	2 Edges, Arc End Mill
PM-2R-D2.0R0.2	4	50	2 Edges, Arc End Mill
PM-2R-D2.0R0.5	4	50	2 Edges, Arc End Mill
PM-2R-D2.5R0.2	4	50	2 Edges, Arc End Mill
PM-2R-D2.5R0.5	4	50	2 Edges, Arc End Mill
PM-2R-D3.0R0.2	4	50	2 Edges, Arc End Mill
PM-2R-D3.0R0.3	4	50	2 Edges, Arc End Mill
PM-2R-D3.0R0.5	4	50	2 Edges, Arc End Mill
PM-2R-D4.0R0.2	4	50	2 Edges, Arc End Mill
PM-2R-D4.0R0.3	4	50	2 Edges, Arc End Mill
PM-2R-D4.0R0.5	4	50	2 Edges, Arc End Mill
PM-2R-D4.0R1.0	4	50	2 Edges, Arc End Mill
PM-2R-D5.0R0.3	6	50	2 Edges, Arc End Mill
PM-2R-D5.0R0.5	6	50	2 Edges, Arc End Mill
PM-2R-D5.0R1.0	6	50	2 Edges, Arc End Mill
PM-2R-D6.0R0.3	6	50	2 Edges, Arc End Mill
PM-2R-D6.0R0.5	6	50	2 Edges, Arc End Mill
PM-2R-D8.0R0.3	8	Product tags mesin cnc milling 5 axis , precision tooling carbide , solid carbide corner radius end mill Send your message to this supplier Message* Email* Phone or WhatsApp* Name Company Please reply me within 24 hours. Yes! I would like your verified suppliers matching service! Send Now Submission successful! 2 Flute Accurate Arc Accuracy Solid Carbide End Mills For Profile Milling Ask Latest Price Product Detail Brand Name : MMM Model Number : Various Certification : ISO 9001 Place of Origin : CHINA MOQ : 5 PCS Price : USD Contact Supplier Zhuzhou MMM New Material Co., Ltd. Active Member 7 Years hunan, zhuzhou Since 2013 Business Type : Manufacturer, Importer, Exporter, Seller Main Products : CNC Carbide Inserts, Carbide Turning Inserts, Solid Carbide End Mills Total Annual : 4 Million-5 Million Employee Number : 50~100 Certification Level : Active Member Discover similar products High Surface Quality Finish Milling 6 Flute Carbide End Mill Flat PVD Coating Contact Now Aluminum Alloy Solid Carbide End Mills With Sharp Cutting Edge / Large Helix Contact Now Wave Edge Solid Carbide End Mills Steel And Aluminum Alloy Roughing End Mill Contact Now Solid Carbide Thread Mills With High Productivity / Excellent Metric Thread Mill Contact Now Profile Milling Solid Carbide End Mills With High Precise Arc / Ball End Mill Contact Now High Precise Arc / Ball Nose End Mill For Aluminum Alloy 2 Flute Carbide End Contact Now High Strength Solid Carbide End Mill Bit For Deep Groove Milling Contact Now Customized And OEM Cemented Solid Carbide End Mills / Four Flute End Mill Contact Now Taper Ball Nose Solid Carbide Tapered End Mills For Vane / Impeller Profile Contact Now Solid Carbide 4 Flute Center Cutting End Mill For ISO S Heat Resistant Alloys Contact Now View More Find Similar Products By Category: Supplier Homepage Products Solid Carbide End Mills MachineU China Products Tools & Hardware Machining Milling Cutter Contact Supplier Message* Email* Phone or WhatsApp* Name Company Submit Requirement Please reply me within 24 hours. Yes! I would like your verified suppliers matching service! Submitted successfully! Your request message has been successfully sent to the supplier. Please keep in touch and they will contact you as soon as possible. OK
