Cutting fluid Dispenser, simple and practical, small in size
Cutting fluid Dispenser, simple and practical, small in size
Specifications
Brand Name :
Diang Tianke
Model Number :
DATK-HPQ
Certification :
ISO9001
Place of Origin :
China
MOQ :
1
Price :
Negotiable
Payment Terms :
LC, T/T, PayPal, Western Union, Small-amount payment, Money Gram
Supply Ability :
5000 Units/Year
Delivery Time :
7-15 workdays
Packaging Details :
wooden case
Model NO. :
datk-py
Installation :
Not Have
Centrifuge Type :
Not Have
Distillation Equipment Type :
Not Have
Extraction Tower Type :
Not Have
Pressure :
High Pressure
Condition :
New
Flow :
1000L/H
Water Tank Capacity :
120L
Compounding Concentration :
0-50%
Transport Package :
Wooden Box
Trademark :
datk
Origin :
China
HS Code :
8401200000
After-sales Service :
Life
Warranty :
One Year
Type :
Centrifuge
Object :
Cutting Fluid
Separation Mode :
Filter Type
Operating Type :
Continuous Type
Description

Cutting fluid Dispenser, simple and practical, small in size

Product Introduction
This liquid dispenser is energy-saving and environmentally friendly, does not require electricity, and has no consumables; It is an automatic mixing and mixing device that only needs to be connected to a water source to work, suitable for use in situations where the mother liquor needs to be diluted with water. Replacing manual liquid preparation, the efficiency is higher, the concentration is more uniform, and the ratio is more accurate. Easy to operate, reliable in quality, and durable.

Product parameters

Adjustable concentration range 0-26% Work efficiency Max 1500L/H
Working water pressure 0.2-0.6mpa Main material Aluminum alloy
Inlet diameter 19mm Water outlet diameter 25mm
Standard length of inlet pipe: 2m Standard length of water outlet pipe 2m

Cutting fluid Dispenser, simple and practical, small in size

Product Features:
1. Anti reverse design, anti reverse structure design to prevent tap water from flowing into the oil tank;
2. Precision control valve, carefully selected precision concentration control valve with locking function to prevent accidental touch and ensure accurate proportioning;
3. Telescopic suction rod, expandable structure, suitable for small and large buckets, easy to use, wide adaptability range;
4. Anti slip fixing, specially designed anti slip fixing nut to prevent slipping during tightening process;
5. High end customization, can be customized with acid and alkali resistant materials, with a long service life;
6. Product quality, every product undergoes testing before leaving the factory to ensure quality assurance.

Operation steps:
  1. The first step is to connect the water pipe to the inlet, pay attention to tightening the inlet to prevent water leakage, connect the outlet pipe and prepare the liquid receiving bucket;
  2. Step two, insert the cutting fluid bucket and fix it vertically;
  3. Step three, open the inlet valve;
  4. Step four, adjust the size of the inlet valve, measure the concentration ratio of the effluent with a refractometer, and make appropriate adjustments to achieve the normal mixing ratio;
  5. Step five, adjust the concentration of the regulating valve to the normal required ratio, tighten the locking nut of the regulating valve to prevent accidental touch from causing concentration changes;
  6. Step 6: Once the ratio is normal, automatic liquid dispensing can be performed.

About Us

Guangzhou Di'ang Tianke Automation Equipment Co., Ltd. is a one-stop intelligent purification solution provider for metal processing fluids, integrating research and development, design, production, and sales. Our main products include intelligent liquid dispensers, oil-water separators, cutting fluid purifiers, machine tool slag removers, industrial wastewater purifiers, and centralized liquid supply purification systems. It is a "National High tech Enterprise", "National Science and Technology oriented Small and Medium sized Enterprise", and "Innovative Small and Medium sized Enterprise", focusing on technology research and development and services, with 30 design and utility model patents.

Cutting fluid Dispenser, simple and practical, small in size

Cutting fluid Dispenser, simple and practical, small in size

after-sale service:
From the date of product sale, our company provides regular quality tracking and follow-up services for the products purchased by users. We provide answers to problems encountered by users in their daily use, solve problems encountered by users during equipment use in real time, communicate and exchange with users about small problems that may occur at each stage of the equipment, prevent equipment failures, detect equipment problems early and eliminate them in a timely manner, to ensure the normal operation of users' equipment.
