Electric 20KG Single Heavy Duty Air Hammer 2.2kw For Forging Steel
Electric 20KG Single Heavy Duty Air Hammer 2.2kw For Forging Steel
Electric 20KG Single Heavy Duty Air Hammer 2.2kw For Forging Steel
Electric 20KG Single Heavy Duty Air Hammer 2.2kw For Forging Steel
Electric 20KG Single Heavy Duty Air Hammer 2.2kw For Forging Steel
Electric 20KG Single Heavy Duty Air Hammer 2.2kw For Forging Steel
Specifications
Brand Name :
Hardware
Model Number :
CC-FGT20
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
USD1300-2000
Supply Ability :
20 units
Delivery Time :
4 weeks
Packaging Details :
sea worthy wooden case
Payment Terms :
T/T, L/C
Specification :
heavy duty
Power :
2.2/220V OR 2.2/380V
Application :
steel parts hammer forging
Hammer weight :
20 kg
Punch force :
0.22KJ
Description

Forging Machine 20KGS Air Hammer Pneumatic Hammer Tools Single Hummer/Single With Base Plate

CC-FGT20 TECHNOLOGY CHARACTERISTICS

Monoblock type

Main technical parameters Unit CC-FGT20
Drop part weight Kg 20
Max. hit energy KJ 0.22
Hit number Min^-1 255
Hight of working area mm 200
Distance from the center of the hammer shaft to the hammer body mm 180
Hammer head mold size mm 90 X 50 X 80
Malleable material diameter Round steel mm Φ 35
Square teel mm 30 X 30
Motor parameters Operating Voltage V 220 380
Power KW 2.2 2.2
Speed R.P.M 1440
Overall dimension mm 820 X 460 X 1100
Total weight Kg 380

CC-FGT20DB TECHNOLOGY CHARACTERISTICS

Main technical parameters Unit CC-FGT20DB
Drop part weight Kg 20
Max. hit energy KJ 0.22
Hit number Min^-1 255
Hight of working area mm 200
Distance from the center of the hammer shaft to the hammer body mm 180
Hammer head mold size mm 90 X 50 X 80
Malleable material diameter Round steel mm Φ 35
Square teel mm 30 X 30
Motor parameters Operating Voltage V 220 380
Power KW 2.2 2.2
Speed R.P.M 1440
Overall dimension mm 1200 X 500 X 1410
Total weight Kg 560

CC-FGT20S TECHNOLOGY CHARACTERISTICS

Split type

Main technical parameters Unit CC-FGT20S
Drop part weight Kg 20
Max. hit energy KJ 0.22
Hit number Min^-1 255
Hight of working area mm 200
Distance from the center of the hammer shaft to the hammer body mm 180
Hammer head mold size mm 90 X 50 X 80
Malleable material diameter Round steel mm Φ 35
Square teel mm 30 X 30
Motor parameters Operating Voltage V 220 380
Power KW 2.2 2.2
Speed R.P.M 1440
Overall dimension mm 820 X 460 X 1445
Total weight Kg 500
