50 Watt CO2 Laser Cutting Engraving Machine , Laser Glass Engraver
50 Watt CO2 Laser Cutting Engraving Machine , Laser Glass Engraver
50 Watt CO2 Laser Cutting Engraving Machine , Laser Glass Engraver
50 Watt CO2 Laser Cutting Engraving Machine , Laser Glass Engraver
50 Watt CO2 Laser Cutting Engraving Machine , Laser Glass Engraver
50 Watt CO2 Laser Cutting Engraving Machine , Laser Glass Engraver
50 Watt CO2 Laser Cutting Engraving Machine , Laser Glass Engraver
50 Watt CO2 Laser Cutting Engraving Machine , Laser Glass Engraver
50 Watt CO2 Laser Cutting Engraving Machine , Laser Glass Engraver
50 Watt CO2 Laser Cutting Engraving Machine , Laser Glass Engraver
Specifications
Brand Name :
Suntop Laser
Model Number :
ST-4060-50
Certification :
CE & ISO9001
Place of Origin :
China
MOQ :
1 set
Price :
USD3250-USD3865
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
170 sets / month
Delivery Time :
9-13 work days
Packaging Details :
Packed with special film, then put inside the plywood wooden box which suitable for air shipping
laser power :
50W ( other power can be optional )
laser type :
Hermetic CO2 glass tube
Laser tube life Span :
1500 working/hours
Applicable Materials :
Acrylic,Glass,crystal,wood,leather,cloth,rubber,marble,ceramic,etc
Working area: :
400*600 mm
Max moving speed: :
1500mm/s
Laser energy control: :
1-100℅ set by hand or software
Worktable :
Fixed honeycomb table/Aluminum table(optional)
Min shaping character: :
Character: 3*3 mm,; letter: 2*2 mm
Resolution ratio: :
≦4500 dpi
Machine size :
1150 * 860 * 740mm
Description

50 Watt CO2 Laser Cutting Engraving Machine , Laser Glass Engraver

1. Machine's general introductions

Our ST-4060-50 model is an affordable, small size laser cutting machine which meet the requirements of small office or workshop, for wood or acrylic processing, 3 phase stepper motor and driver, work with high efficiency, energy saving, good performance .

This kinds of CO2 laser engraving machine with advanced and mature DSP control system, which has the function of "power off memory" and "automatic standby model", Laser tube - fine laser beam, good effect for cutting & engraving .

We adopt the HIWIN linear square guide, work stable & high precision, material can be delivered unlimited from front to back, aluminium flat & Strip working table, greatly increased machine values, adjustable table , material can reach 39 cm thick, red laser pointer for easy job set up

2. Application materials

Acrylic, plexiglass, PMMA, wood, plywood, MDF, marble, paper, glass, cloth, leather, rubber, cork etc, non-metal material engraving and cutting.

3. Application industry

Wood industry, advertisement industry, Decoration industry,leather industry, shoes industry, and trademark industry etc, it's mainly used for the engraving and cutting of little artistic works. Such as engraved portraits,badges, breast cards and various engraved packages. It can also engrave seals and crabs.

4. Machine technical specifications

Laser power :

50 W(optional)

Laser tube life Span

1500 working/hours.

Applicable Materials

Acrylic,Glass,crystal,wood,leather,cloth,rubber,marble,ceramic,etc.

Working area:

300*500 mm

Max moving speed:

1500mm/s

Laser energy control:

1-100℅ set by hand or software

Worktable(optional):

Manual up and down table/fixed table/honeycomb table/Aluminum table

Locating precision:

<0.01 mm

Min shaping character:

Character: 2*2 mm,; letter: 1*1 mm

Operating temperature:

5℃-35℃

Resolution ratio:

≦4500 dpi

Laser type:

Hermetic CO2 glass tube

Power supply:

AC220±10℅50 HZ/AC110±10℅50 HZ

Control configuration:

DSP.

Data transfer interface:

USB (offline).

USB Ports

2

System environment:

WINDOWS 2000/WINDOWS XP/MAC/Vista

Cooling way:

Water cooling and protection system

Graphic format supported:

The file which CorelDraw, Photoshop, AutoCAD can identify(BMP,GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG,

DXP,PAT,CDT,CLK,DEX,CSL,CMX,AI,WPG,WMF,EMF,CGM,SVG,SVGZ,PCT,FMV,GEM,CMX).

USER MENU

Full English.

Package Inclusion

Software,VIDEO USER MENU CD,Air pump gun,Power cables, USB cables, Water pump,Water Pipe,Smoke Vent-pipe,Air Blow Pipe ,exhaust fan,Tools bag

Memory

64 MB

Display screen

LCD(SIZE 70*40 mm)

Protection System

Yes

Option parts

high-grade cooling system/double-head/cylinder rotary Jig/ irregular rotary Jig/ honeycomb table/ knifes table

Guarantee

1 year ,damageable spare parts(like laser tube,mirrors) 3 months

Dimensions

1020*650*590 mm

Dimensions(package)

1140*770*670 mm

Net Weight

78KGs

Gross Weight

105KGs

Recommended Ship way

Air
5. The cutting thickness data for reference ( customer can choose the corresponding power )

Materials

40W

50W

60W

80W

100W

120W

150W

Wood

3mm

5mm

7mm

10mm

12

13mm

15mm

Playwood

2mm

4mm

6mm

10mm

12mm

13mm

15mm

Glass

Leather

1mm

2mm

3mm

4mm

5mm

6mm

7mm

Acrylic

2mm

5mm

10mm

13mm

15mm

17mm

20mm

PVC

1mm

2mm

3mm

4mm

5mm

6mm

7mm

Plexiglass

1mm

2mm

4mm

8mm

10mm

12mm

15mm

Plastic(easy to melt)

1mm

1mm

2mm

3mm

4mm

5mm

6mm

Rubber

2mm

3mm

3mm

4mm

5mm

6mm

7mm

Crystal/Jade/Stone/Marble/medal

Clothing(fabric,wool)

2mm

3mm

3mm

4mm

5mm

6mm

8mm

Bamboo Works

1mm

2mm

3mm

4mm

5mm

6mm

7mm

Paper

0.5-5mm

6. Machine's real cutting and engraving samples

50 Watt CO2 Laser Cutting Engraving Machine , Laser Glass Engraver

50 Watt CO2 Laser Cutting Engraving Machine , Laser Glass Engraver50 Watt CO2 Laser Cutting Engraving Machine , Laser Glass Engraver
