M1020A centerless grinding machine for grinding slender cylindrical workpieces
M1020A centerless grinding machine for grinding slender cylindrical workpieces
M1020A centerless grinding machine for grinding slender cylindrical workpieces
M1020A centerless grinding machine for grinding slender cylindrical workpieces
Specifications
Model Number :
M1020A
Certification :
CE,ISO
Place of Origin :
china
MOQ :
1 pieve
Payment Terms :
L/C, D/P, T/T, D/A, Western Union, MoneyGram
Delivery Time :
15-20 days after received payment
Packaging Details :
Standard export packaging
Name :
Precision Grinding Machine M1020A
Condition :
New
Voltage :
220V/380V
Warranty :
1 Year
The wheel speed :
10-180r/min
Machine weight :
2000kg
Description

M1020A centerless grinding machine for grinding slender cylindrical workpieces

M1020A centerless grinding machine for grinding slender cylindrical workpieces

The M1020A is suitable for grinding slender cylindrical workpieces, short shafts without center holes, and nested workpieces. When cutting into the grinding, radial feed is achieved by the movement of the guide wheel frame or the grinding wheel frame, which is suitable for grinding workpieces with shoulders or bosses, as well as cones, spheres or other workpieces whose curves are curved. Centerless grinding machines have high productivity, and are easy to automate with various loading and unloading devices. Most of them are used for mass production and can be operated by less skilled workers.

M1020A centerless grinding machine for grinding slender cylindrical workpieces

M1020A Centerless Grinder Machine Features
1. The machine layout adopts the guide wheel frame to move on one side.
2. The grinding wheel shaft adopts an overhanging structure, which is convenient to replace the grinding wheel.
3. The guide wheel shaft adopts multi-plate dynamic pressure oil film bearing, and the speed regulation adopts AC frequency conversion stepless speed regulation.
4. Equipped with long workpiece through grinding bracket

M1020A centerless grinding machine for grinding slender cylindrical workpieces

M1020A centerless grinding machine for grinding slender cylindrical workpieces

Grinding dia(mm) Thru-feed 0.5-20mm Grinding length(mm) Thru-feed 80mm
Plunge feed 3-20mm Plunge feed 80mm
The rotation angle of guide wheel In vertical plane -2°~+4°
Machining accuracy		 Roundness(μm) 2μm
In horizontal plane -1°~+3° Cylindricity(μm) 2.5μm
Height from centerline of gri.wheel & reg.wheel to workrest(mm) 170mm
Gri,wheel spec(mm) PSA300*100*127 Reg.wheel.spec(mm) PSA200*100*75
Gri,wheel speed(r/min) 2100r/min The wheel speed 10-180r/min
Total power of machine(kw) 5.35kw Machine weight(kg) 2000kg
Overall dimensions(mm) 1750*1290*1350mm Feed rate of hanwheel perdivision(mm) 0.002㎜
