24T Magazine CNC Horizontal 3 Axis Machining Center 6000 RPM Spindle Speed

CNC Horizontal Machining Center Features:

Taesin CNC Horizontal Machining Center use a special lineary way for the whole machine. This kind of linear way provides outstanding full support across the entire axis travel and more stable work table platform. Even for heavy cutting and some challenging cutting, this structure can ensure stability, rigidity and precision of motion. linear guide way which can reduce friction, resistance and effects of temperature change during axial quick movement. Also, it can result high precision of machined products and high capacity of machining output. Moreover, the pre-tensioned and large diameter ballscrew and powerful digital servo motor can provide the axis thrust and good performance. Quick motion can minimize the non-productive time on positioning moves that decreases cycle times and cuts part costs.

For the base, Taesin CNC Horizontal Machining Center has bigger span in the base to ensure high rigidity and smooth performance. Saddle is made wider and thicker than traditional to improve the ability to do heavy cutting and processing.

T-type Base Structure, High-rigidity and Slide Way Support, Gantry Column, High Rigidity Saddle Base, Strong Spindle Support

X/Y/Z Feeding Drive System: High-torque Servo Motor Directly Connected with Φ50 Ball Screw by Coupling; Both Ends of Ball Screw are Fixed and Pre-stretched. High Transmission Rigidity Structure Ensure the Positioning Precision.

Spindle Transmission System: Servo Motor Direct Transmission to High-precision Spindle; Higher Transmission Efficiency, Lower Noise and Vibration; ContinuousOutput Power for Higher Processing Efficiency; Specially-designed Spindle from Taiwan

Anti-collision Design to Prevent Nut Base, Motor Base and Bearing Base from Colliding with Each Other for Protect the Machine Precision

One-piece Oil-water Separation System Ensures that Polluted Lubricant and Coolant Flow Back Separately, and prevent the coolant from being polluted

CNC Horizontal Machining Center Technical Data:
