Specifications
Brand Name :
DZ
Model Number :
HZ-360
Certification :
CE ISO
Place of Origin :
China
MOQ :
1set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
30sets/per month
Delivery Time :
20days
Packaging Details :
wood
Description
Detail Information
Color:Silver Gray And SaffronName:Shell Core Shooter Machine
Condition:NewTechnology:Resin Sand Technology
Size Of Heating Plate:350x200mmTransmission Speed:72mm/s
High Light:

shell core shooter machine,cold box core shooter machine

Product Description

automatic core shooting machine with the functions of vertical parting , It is suitable for small and medium-sized work


Machine Application and Scope of Application

HZ 360-HS core shooting machine is a kind of automatic core shooting machine with the functions of vertical parting, full automatic, down-turning die, conveyor belt to convey sand core and automatic mixed sand lifting. It is suitable for small and medium-sized work pieces in valve, faucet, hardware, hydraulic and pneumatic industries. It also applied to the hot core sand and coated sand of furan resin series hot box sand and urea-formaldehyde resin series. It is especially suitable for copper and aluminum casting industry, which can meet the core-making requirements of the core-shooting process with three-component resin, complex core shape and low structural strength.

Technical parameters

1BASIC EQUIPMENTSpecifications
Max. Sand Core Weight9kg
Max. Cor Box size(L*W*H)(450*330*220)mm
Heating Plate(L*W)(400*300)mm
Heating Power9.6kw
Clamping stroke of the shooting head≤30mm
Die-opening Stroke≤300mm
Max.Core Pulling Stroke150mm
Conveyor Belt(L*W*H)(2200*450*100)mm
Machine Power2°~4°
Conveyor Speed72mm/s
Machine Dimension(L*W*H)(3500*1480*3400)mm
Lifting Speed(single cycle)35s
Lifting Capacity(Single cycle)5~10kg
Machine weight2000kg



Reliable Control Sand Core Making Machine With Vertical Parting FunctionsReliable Control Sand Core Making Machine With Vertical Parting Functions

Reliable Control Sand Core Making Machine With Vertical Parting FunctionsReliable Control Sand Core Making Machine With Vertical Parting Functions

Packaging & Shipping
1.Outside package: Standard export wooden cases;
2.Inner package: Stretch film;
Shipping: Container transport.
