Horizontal Shell Core Shooter Machine , Foundry Moulding Machine ISO Approved
Horizontal Shell Core Shooter Machine , Foundry Moulding Machine ISO Approved
Specifications
Brand Name :
DZ
Model Number :
HZ-360
Certification :
CE ISO
Place of Origin :
China(Mainland)
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
30 sets/per month
Delivery Time :
2 weeks
Packaging Details :
wood
Max. Weight of Sand Core :
8kg
Max. Size of Core Box ( L x W x H) :
（450*330*220）mm
Heating Plate ( L x W) :
（400*300）mm
Heating Power :
9.6kw
Downward Stroke of Ejection Head :
≤30mm
Stroke of Mold Opening :
≤300mm
Max. Stroke of Core Remove :
150mm
Conveyor ( L x W x H) :
（2200*450*100）mm
name :
foundry core making machines
Rising Angle of Conveyor :
2°~4°
Description

Horizontal Shell Core Shooter Machine , Foundry Moulding Machine ISO Approved

Machine construction features:

1. human-machine interface and imported high quality electronic control and pneumatic components to ensure accurate and reliable control and easy operation.

2. there are three modes: manual, single action and automatic.

3. the shooting port is 70 degrees to the sand, away from the high temperature area, so that the perforation is easy to manually clean.

4. The machine is equipped with integral moving mechanism of the base, which can make the base move along the X and Y axes, so that the perforation of the opposite mold into the sand hole more convenient and accurate.

5. The movable die is equipped with the core pulling rack to meet the special requirements of the mold. If you do not use core pulling, close the core pulling switch.

6. The angle of the quicksand in the sand storage bucket reaches 70 degrees and is equipped with a vibrating motor. It is suitable for the use of collapsible core sand with poor fluidity in the copper casting and aluminum industry.

7. With mold adjustment space, it is convenient to assemble different molds and reduce the requirements for the die size.

Horizontal Shell Core Shooter Machine , Foundry Moulding Machine ISO Approved

Horizontal Shell Core Shooter Machine , Foundry Moulding Machine ISO ApprovedHorizontal Shell Core Shooter Machine , Foundry Moulding Machine ISO Approved
