High Precision Aluminum Prototype CNC Machining For Reducer Housing
High Precision Aluminum Prototype CNC Machining For Reducer Housing
High Precision Aluminum Prototype CNC Machining For Reducer Housing
High Precision Aluminum Prototype CNC Machining For Reducer Housing
Specifications
Brand Name :
Shinden
Model Number :
Precision Aluminum Prototype CNC Machining Reducer Housing
Place of Origin :
China
Payment Terms :
L/C, D/A, D/P, T/T
Delivery Time :
7-45 work days
Packaging Details :
wooden case/carton,or according to customer's needs
Description
Product Description

The main technical requirements of the Reducer Housing.

High Precision Aluminum Prototype CNC Machining For Reducer Housing

The main processing parts of the separated Reducer box are: bearing support hole, joint surface, end face, base (assembly base), upper plane, bolt hole, thread hole, etc. It can be manufactured by CNC engraving, Sand Casting, transparent acrylic(PMMA/PC) 3D Printing. The technical requirements for these processing parts are:
1, the reducer box, the upper plane of the cover and the combined surface and the bottom surface of the body and the combined surface must be parallel, and the error is more than 0.06/1000mmK
2, the surface roughness of the reducer box joint surface Ra plant does not exceed the gap between the two joint surfaces does not exceed 0.03m, take 0.02mm.
3. The axis of the bearing support hole must be on the joint surface, and the error shall not exceed 0.2mm.
4. The dimensional tolerance of the bearing support hole is generally HT, the surface roughness Ra is less than 1.6m, the cylindricity error is not more than half of the aperture tolerance, and the hole distance accuracy tolerance is 0.03mm~ 0.05mm.
5, the bottom surface of the reducer box is the installation benchmark, to ensure the accuracy of 0.2mm.

6. The screw holes on each surface of the reducer box have position requirements, and the position tolerance is 0.15mm

High Precision Aluminum Prototype CNC Machining For Reducer HousingHigh Precision Aluminum Prototype CNC Machining For Reducer Housing

Company Overview

Established in 2010, Wuxi SHINDEN Modern Intelligent Technology Co.Ltd aims to become a first-class rapid manufacturing enterprise in China.

We are committed to helping companies' R&D and innovation by providing product display solutions and test prototype solutions.

Product display package solutions include delicate process display machine solutions, cutaway display machine solutions and transparent appearance display machine solutions, from processing, assembly to simulation of dynamic operation. The design and manufacture of the display stand is easy to assemble and disassemble, convenient for packaging and transportation, multiple solutions to choose from and professional customization to meet the multi-functional needs of different customers.

Small batch prototype solutions-engraving, short-cycle rapid prototype, suitable for new product development A sample, B sample stage. Small and medium batch prototype solutions - Casting, close to the characteristics of mass production die casting, suitable for new product development B and C stage and mass production up to 20,000 units/year. Test prototype solutions also include lubrication test, divided into transparent and translucent solutions, we have many years of rich experience in design and production, and we can customize solutions according to customer needs. We promise to provide professional and refined services to make our customers' products presented in the best way and help our customers’ R&D in the shortest time.

In the automotive field, we mainly serve the whole vehicle enterprises and core parts companies, with the service coverage of whole vehicle enterprises exceeding 95% and total service projects exceeding 10,000. We are also providing prototype and rapid medium and small batch manufacturing services for construction machinery, medical equipment, aviation and other industries. While deeply cultivating the domestic market, we are also carefully exploring foreign markets, mainly serving customers such as BorgWarner, Volvo, Bunch, Atlas, etc., mainly in Europe, North America, Oceania and other places.
