2000x6000mm 7.5KW UT2060A Woodworking CNC Router Machine
2000x6000mm 7.5KW UT2060A Woodworking CNC Router Machine
Specifications
Brand Name :
Unitec
Model Number :
UT2060A
Certification :
ce
Place of Origin :
Unitec
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T, L/C, Western Union
Delivery Time :
10-15 working days
Packaging Details :
wooden case for outer packing
Spindle Power :
6KW/5.6EL China air cool spindle or 5.6KW Italy Air cool spindle
Max Travel Speed :
30000mm/min
Spindle Speed :
18000rpm
Max Work Speed :
20000mm/min
XYZ Travel Size :
2050X6050X200mm
Max Working Size :
2000X6000X150mm
Transmission Type :
XY/Z XY rack/Z ball screw
Guide Rail :
Linear Guide
Description

UT2060A CNC Router machine 2060 large working size CNC Router 2000x6000mm long table woodworking machine​

Feature of cnc router 2060:

  • Ball screw for Z axis,it's stable running and precision.
  • X Y axis are gear rack,it's stable running,precision and fast.
  • Syntec control system easy to learn operate and more precision.
  • This atc wood cnc router designed with inline type auto tool changer.Difference tool can be installed in tool holder.Spindle working one by one,more convenient to change the tool,high efficiency and save time.
  • Heavy duty frame and gantry,it's very strong and stability.

Applications and Materials

  • Furniture Industry: wood doorcabinetclassic furniturepanel furnitureetc
  • Woodworking Industry: Automotive TrimStereo EquipmentInstrumentsOffice FurnitureCloset,etc
  • PVC Crafts Industry: solid woodartificial stonemarblesandstonealuminum composite panelbamboosoft metalPVCacrylicdouble color board, etc

Technical parameters

XYZ Travel Size

 2050X6050X200mm

Max Working Size

 2000X6000X150mm
Table Size 2050X6000mm
Transmission Type XY/Z XY rack/Z ball screw
Guide Rail Linear Guide
Table Type vacuum
Vacuum Pump 7.5KW/4.8KW 7.5KW water recycle cool pump or 4.8KW air pump
Spindle Power 6KW/5.6EL China air cool spindle or 5.6KW Italy Air cool spindle
Spindle Speed 18000rpm

Max Travel Speed

 30000mm/min
Max Work Speed 20000mm/min
Motor servo motor
Work Voltage AC380V 50HZ
Controller System Ncstudio

Processing Accuracy

 0.05mm

Repeat Positioning Accuracy

 0.01mm
File Format G/PLT G code or PLT
Overall Weight 3500KG
Overall Dimension 2500X6600X1900mm

  • Integral welded Frame, mounting surface of guide ail and rack processed by high-precision milling machine, ensure the machine running stability
  • Various of table styles makes convenient clamping materials and improves overall production efficiency
  • Smooth bottom surface, clear edge contour and fine processing quality.
  • Main configurations adopts imported accessories which will ensure the overall running performance
  • CE Strict compliance with CE electrical standards for circuit design and production, and all
  • Parts have safe and reliable protection device.

Certificate

  • CE certificated for European countries

  • CCVO SONCAP certificated for Nigeria customers

  • FTA certificate for Pakistan customers

  • SASO certificate for Saudi Arabic customers

  • Form E certificate for Indonesia and Vietname customers

Packaging & Delivery

Packaging Details:

  • Outside package: Standard marine export plywood case.
  • Inner package: Three layers in total; EPE pearl cotton film+PE stretchy film.

Improved package, much more strong and environmental protection.

We can also make package according to your requests.

Delivery Detail: Shipped in 25-30 working days after payment
