Wire Rotary Cnc Forming Machine With Max Fourteen Axes High Precision
Wire Rotary Cnc Forming Machine With Max Fourteen Axes High Precision
Wire Rotary Cnc Forming Machine With Max Fourteen Axes High Precision
Wire Rotary Cnc Forming Machine With Max Fourteen Axes High Precision
Wire Rotary Cnc Forming Machine With Max Fourteen Axes High Precision
Wire Rotary Cnc Forming Machine With Max Fourteen Axes High Precision
Wire Rotary Cnc Forming Machine With Max Fourteen Axes High Precision
Wire Rotary Cnc Forming Machine With Max Fourteen Axes High Precision
Wire Rotary Cnc Forming Machine With Max Fourteen Axes High Precision
Wire Rotary Cnc Forming Machine With Max Fourteen Axes High Precision
Wire Rotary Cnc Forming Machine With Max Fourteen Axes High Precision
Wire Rotary Cnc Forming Machine With Max Fourteen Axes High Precision
Specifications
Brand Name :
HYD,Dongguan
Model Number :
HYD-40T-12A
Certification :
CE / IS09001
Place of Origin :
Dongguan,China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, D/A, T/T, Western Union, MoneyGram
Delivery Time :
30 Days
Packaging Details :
Standard Seaworthy Plywood Case
Wire Range :
Spring Steel 1.0-4.0mm
Factory :
Dongguan,China
Number of wire feed axes :
4 Sets
Advantage :
Fast,easy to operate
Servo Motor :
Japan
Voltage :
380V
Machine Color :
Blue or customized
Description

Wire Rotary Spring Forming Machine with Max Fourteen Axes High Precision

Model HYD-40T-12A
Number of Axis 12 Axes
Wire Diameter low carbon steel:2.0-6.0mm
high-carbon steel:1.0-4.0mm
Lead rail distance of 100mm
Number of Wire feed 4 pairs
Max Feed speed 100m/min
Max error ± 0.05mm(length)
Control system+decoiler equipment 1 set
Servo motor power 27KW
Reducer 11 pcs
Minimum length of ange 4 times wire diameter
Machine size 1920*1200*1820mm
Machine weight 3000KG

Machine Details:

1. Equipped with the computer-controlled system imported from Taiwan and servo motor imported from Japan.

2. The parameters such as major diameter and angle can be modified at any time according to the working status displayed on the fluorescence screen.

3. It is suitable for producing double torsion spring, straight spring, pagoda-shaped compression spring, rectangle spring, swirl spring and other different spring and special-shaped spring etc.

Machine Manufacturering Picture:

Wire Rotary Cnc Forming Machine With Max Fourteen Axes High Precision​

Wire Rotary Cnc Forming Machine With Max Fourteen Axes High Precision

Packaging & Delivery

---Packaging Details in standard sea-worthy 2 plywood-cases to pack this machine,

Delivery Port

---Shenzhen or other specially designated port.

Company Introduction

----HYD is a production and sales combined company, with more than 15 years experience in spring machine industry, which make us become a experienced and reliable supplier.HYD manufacture CNC spring machine,wire bending machine,spring coiling machine ect,all of them are CNC,automatic.
