Three Axes CNC Spring Forming Machine 5.5KW High Power For Wire Szie 4.2mm
Three Axes CNC Spring Forming Machine 5.5KW High Power For Wire Szie 4.2mm
Specifications
Brand Name :
HYD
Model Number :
HYD-40T-3A
Certification :
CE / IS09001
Place of Origin :
Dongguan,China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
Negotiable
Supply Ability :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
15 Days
Packaging Details :
Standard Seaworthy Plywood Case
Axis :
Three Axes
Optional Tools :
Spinner/Machine hand
Payment Term :
T/T
Port :
Shenzhen,China
Description

Spring Bending Machine & Spring Forming Machine for Wire Szie 4.2mm

HYD-40T-3A is with three axes,we have optional tools like spinner,machine hand,servo scissors as

additional axis.This machine is without wire rotation function,HYD-40T-12A is with wire rotation.We can
always customize the machine according to customer's requirement.
Diameter 0.8~4.2mm
Max OD 60mm
Wire Feeding speed 0~110m/min
Transmission speed cam 0~60RPM
Wire feed servo motor 5.5KW
Can servo motor 5.5KW
Rotary servo motors 1.0KW
Power 380V±10%V50Hz
Machine size 1600*1300*1900mm
Machine Weight 1800kg

Samples:

Three Axes CNC Spring Forming Machine 5.5KW High Power For Wire Szie 4.2mm

HYD Service:


1. Free training is provided in HYD production base.Pictures and video of the machine operation will be sent for confirmation before shipment.

2 .The professional and patient consulting service will help you find the suitable solution.

3. Quick and safe shipment as per your requirement including the booking ,container loading, and shipping documents.

4. HYD provide technical support by email and phone,technicians will be available at your side if necessary.

5. Spare parts will be freely supplied during the guarantee period(one year), original cost after this period.
