Specifications
Brand Name :
HYD
Model Number :
HYD-60T-16A
Certification :
CE / IS09001
Place of Origin :
Dongguan,China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, MoneyGram, Western Union
Delivery Time :
20 working days
Packaging Details :
Standard Seaworthy Plywood Case
Supply Ability :
1500 SETS PER YEAR
Model :
HYD-60T-16A
Number of Axis :
Sixteen Axes
Sample Provided :
Yes
Servo Motor :
Japan
CNC Computer :
Taiwan
System :
English/Chinese
Place of origin :
Dongguan,China
Machine Weight :
4500KG
Description

Wire Forming Machine and Spring Machine Combined Function with Sixteen Axes

1.Machine Features

--This machine has total 16 axes which are Cam axis, Feeding axis, Quill Rotary axis, the Wire rotary axis and the Spinner axis.

--This machine is with servo motor from Japan and control system from Taiwan.

--This machine combine the function of spring machine and wire forming machine,the wire bending part can be taken off from the machine when producing spring.And put it back when need to make wire forms.

--This type of versatile spring making machine is of functions of both wire forming and spring making

--We adhere to the principle of cost-saving, and performance-improvement, in a word, absolutely it will be your perfect choice for spring making.

2.Technical parameters

Wire Size range

 steel wire:2-6mm
iron wire:3-8mm
Maximum wire length Unlimted
Max feeding speed 80m/min
Wire Feeding wheel count 4 pairs
Motor power consumption 59KW
Reducer 13 pcs
Machine size 4000*2100*2300mm
Weight

4500kg

More details connect with Jacy

WhatsApp & Tel +86 13925873992


3.Packaging and Delivery

Packaging:Standard Export Fumugated Wooden Case

Delivery:4-6weeks after payment

4.Spring Samples and Decoiler Equipment

High Efficiency 8mm 16 Axes Camless CNC Spring Forming Machine Automatic Wire Forming Machine Making Wire Manufacturers

High Efficiency 8mm 16 Axes Camless CNC Spring Forming Machine Automatic Wire Forming Machine Making Wire Manufacturers

5.Packaging & Shipping
High Efficiency 8mm 16 Axes Camless CNC Spring Forming Machine Automatic Wire Forming Machine Making Wire Manufacturers

High Efficiency 8mm 16 Axes Camless CNC Spring Forming Machine Automatic Wire Forming Machine Making Wire Manufacturers

6.Service Support:

---Durable quality of machine and the most professional service would be provided.

---Free solution for your production will be provided. The staff in HYD company are with rich experiecnce,best solution will be provided all the time.

---Your visiting to HYD company for checking or training is warmly welcome.
