Optical 2D Measuring Machine Digital Vision Measurement System With Granite Structure
Optical 2D Measuring Machine Digital Vision Measurement System With Granite Structure
Optical 2D Measuring Machine Digital Vision Measurement System With Granite Structure
Optical 2D Measuring Machine Digital Vision Measurement System With Granite Structure
Specifications
Brand Name :
AUSKY
Model Number :
AQC320
Certification :
CE, ISO
Place of Origin :
Guangdong, China (Mainland)
MOQ :
1
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
200 sets per month
Delivery Time :
3 Work days
Packaging Details :
Export wooden case
Outline dimension :
740*660*970mm
Actual run size :
300X200X200mm
Display resolution :
1/0.5um Optional
The camera :
High definition Color 1/3''CCD camera
Total video magnification :
30-190X
Raster resolution :
0.001mm
Working Distance :
96mm
Weight :
350KG
Description

Quality Assurance Factory Price Digital Vision Measurement

Instrument Features :

1.Adopt AQC series measuring software for processing and output ,Powerful and complete functions,available for manual program measuring .

2.Adopted high-precision granite structure ,never deformation, high stability,

high-end good looking.

3.High precision grating system, with extremely high stability .

4.Adjust through LED light source software ,easy to operate.

5.Adjust high precision polish rod transmission , enabling to fine tune and move rapidly ,achieve more high efficiency measuring .

6.Software focusing indication function , well -illustrated report output system .

Technical parameters

Paramter and Model

AQC320

Workbench

Platfom size(mm)

460X360

Glass table size(mm)

350X250

Bearing(kg)

20

Travel

X axis(mm)

300

Y axis(mm)

200

Z axis(mm)

200

Image and measurement system

Display resolution(mm)

1/0.5(Optional)

Instrument precision(um)

(3+L/200)um

Imaging system(CCD)

HD color 650TV

Zoom objective(X)

Zoom objective 0.7~4.5X

Total video magnification(x)

30~200X

Working distance(mm)

96mm

Light source

LED programmable partiton light source(Coaxial light source optional)

Outline dimension(mm)

610X550X970

Weight(kg)

250kg

Power supply

220V AC 50Hz

Optical 2D Measuring Machine Digital Vision Measurement System With Granite Structure

Main accessories

Optical 2D Measuring Machine Digital Vision Measurement System With Granite Structure

Company profile

Located at Shenzhen city, Baoan District Guangdong Province.High-tech enterprise integrating R & D and production.

Mainly engaged in video measuring system,have been professional in the industry of video measuringsystem for 15 years.

Products widely applied in industrial applications such as machines,

electronics, molds, plastics, metals, die-cutting, electrical appliances, mobile,

phone, home appliance, computer, LCD TV, printed circuit board (PCB), automotive, aviation etc.

AUSKY always carries on the scientific manage system ,strong adhere to the policy :Quality Firstly,Customer Firstly and Credit Firstly .

We also have a perfect after sale service system ,These can ensure that we provide customers with the best products and services.

Optical 2D Measuring Machine Digital Vision Measurement System With Granite Structure

Servics

Optical 2D Measuring Machine Digital Vision Measurement System With Granite StructureOptical 2D Measuring Machine Digital Vision Measurement System With Granite Structure

RFQ

1. How to Choose the Appropriate Specification

After get your demand,our professional team will work out best solutions by sending catalogue specification,demonstration video or other methods according to customers' need.

2. What is the delivery term of your products?
Normally we have standard products in stock. For bigger sizes (larger than 1000mm),

we can discuss and determine on the delivery time, generally,7-10 working days after receipt of the

payment. in urgent , we will try to make special arrangement.

Various shipping modes choices,shipping from Shenzhen port.

3. Do you accept customized service?
Yes OEM is welcome .

4. What is your warranty period?

12 Months warranty,after the warranty,the professional after-sales service team will provide comprehensive technical support to help customers solve problems encountered when using our products and promptly handle customer problems and complaints.

5.Have you ever had clients in our country before?

Our equipment has been widely supplied to Malaysia,India,Japan, Pakistan, Philippines, Singapore,Thailand and Vietnam, Korea, UK, Italy, Germany,USA, Poland, Russia,

Turkey,Mexico,Ecuador,Canada,Israel and so on more than 30 countries.

6.How to install and use your product .

We will provide operating instructions and video of English version, if near our agent,the spot service is easier or we can send engineer to your country to finish installation and training,it takes extra cost like air-ticket and accommodation .

Package

Optical 2D Measuring Machine Digital Vision Measurement System With Granite Structure

Optical 2D Measuring Machine Digital Vision Measurement System With Granite Structure
