Specifications
Brand Name :
Johnbull
Model Number :
702
Certification :
ISO
Place of Origin :
CHINA
MOQ :
1 unit
Payment Terms :
T/T,, Western Union
Supply Ability :
150 units/month
Delivery Time :
within 25 days after receipt of downpayment
Packaging Details :
complete or in iron crate
Type :
Crawler tractor
Track :
Triangular track
Steering :
with Steering Wheel
Angle of Turn :
90 degrees
Rated Power :
51.5 KW
Dimensions of Tractor :
3690X1500X2400 mm
Machine Weight :
2255 KG
Engine :
Direct injection,Vertical,Water-cooled,Four-stroke Diesel Engine
Transmission Type :
Eight forward gear + eight reverse gear
PTO :
Type I, non-independent
Description

New 70HP Farm Crawler Track Tractor with Steering Wheel for Rice Paddy and Dry Field

Rubber Crawler tractor with differential steering mechanism controlled by Steering Wheel has

the following advantages.

1. strong controllability,

2. flexible maneuverability,

3. less effort in turning,

4. greatly improves the speed of operation,

5. improves the adaptability of road transfer.

Features:

Comparison with wheeled Tractor

ITEM Crawler Tractor Wheeled Tractor
Traction Force 1.4~1.8 1
Traction Effective 70~80% 55~65%
Ground Pressure 47.7KPa (with 95.6 KW engine) 104KPa (with 95.6 KW engine)
Maintenance More Easily as Regid Frame Structure disassembly
Fuel Consumption 0.75 1

Technical Data:

Model JB702
Size Length x Width x Height (mm) 3690 x 1500 x2400
Weight (kg) 2255
Minimum ground clearance (mm) 395
Engine Model YD4CZ70C1
Form Direct injection,vertical,water-cooled,
four-stroke
Rated power (KW) 51.5
Fuel Diesel fuel
Rated speed (r/min.) 2400
Starting method Electric start
Steering Brake System Steering system type Planetary differential steering
Brake system type Wet friction type
Drive Train Clutch type Single-chip single fuction clutch
Transmission type 8 forward gear + 8 reverse gear
Transmission shift mode Gear shift
Walking System Rack form Rigid frame type
Track pitch section x number x width 90 x51 x350
The theoretical speed of each file(km/h) Forward:1.22;1.80;2.92;3.84;5.50;8.08;13.13;17.25
Reverse:0.97;1.43;2.32;3.04;4.36;6.41;10.42;13.68
Working Device Lifter type Semi-Split
Tillage depth control Force adjustment
PTO form Type I, non-independent
Power output shaft speed (r/min) 720/1000
PTO shaft spline and the outer diameter (mm) 8 x 38

New 70HP Farm Crawler Track Tractor with Steering Wheel for Rice Paddy and Dry FieldNew 70HP Farm Crawler Track Tractor with Steering Wheel for Rice Paddy and Dry FieldNew 70HP Farm Crawler Track Tractor with Steering Wheel for Rice Paddy and Dry Field
