Flexible Structure Cng Service Station Large Capacity Low Gas Leakage Rate
Flexible Structure Cng Service Station Large Capacity Low Gas Leakage Rate
Specifications
Brand Name :
JINGXIN
Model Number :
JXJQ-Y100
Certification :
ISO
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
20 per month
Delivery Time :
60 days
Packaging Details :
Wooden box
Configuration :
customer made
Power source :
AC power
After-sales service provided :
Engineers available to service machinery overseas
Dimension(l*w*h) :
Vary
Warranty :
1 year
Voltage :
380 V
Working pressure :
25 MPa
Inlet pressure :
3-20 MPa
Description

Engergy saving high capacity Hydraulic psiton pump CNG service station

Application:

The hydraulic piston pump CNG service staion is used for CNG daughter station.

Description:

The hydraulic psiton CNG serivce station make the reciprocating motion in cylinder through the hydraulic system by pushing the piston.

Advangtages:

1. Different capacities: from 1000 to 3000 Nm3/h.

2. Different types of CNG service station for choose: split type, intergrated type and partial intergrated type. Selection is more flexible.

3. Little mechanical vibration, smooth systme runnig and low noise.

4.Less wearing parts. Most of the parts are standard. Easy to repair with low maintenance cost.

5. It is high efficient and energy saving. It can save about 20% engergy compared with mechanical piston compressor.

6. Gas leakage rate ≤0.02%. it is lower 0.1% than the mechanical piston compressor's standard.

Flexible Structure Cng Service Station Large Capacity Low Gas Leakage Rate

Technical parameters

Iitems Unit Parameters
Inlet pressure Mpa 3-20
Outlet pressure Mpa 25
Inlet Temp. ℃ <30
Outlet Temp. ℃ ≤45
Capacity Nm3/h 1000-3000
Motor power KW <100
