High Effeciency Easy Operation CNG Dispenser Ball Valves For Compressed Natural Gas
High Effeciency Easy Operation CNG Dispenser Ball Valves For Compressed Natural Gas
Specifications
Brand Name :
JINGKE
Model Number :
JKJQ-30-II, C
Certification :
ISO
Place of Origin :
China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T
Supply Ability :
150 sets per month
Delivery Time :
20 days
Packaging Details :
Wooden box
Material :
Stainless steel
Color :
as required
Application :
compressed natural gas
Working pressure :
≤25 MPa
Temperature range :
-35℃～+55℃
Warranty :
1 year
Flow rate :
1～30 kg/min
Power :
AC220V
Nozzle :
Auto shutoff nozzle
Hose :
Anti-static rubber hose
Description

High effeciency easy operation CNG Dispenser ball Valves CNG Gas Dispenser

Description:

The CNG dispensers are designed with a stainless steel strong structure and can be configured according to the needs of each refueling station for medium capacity vehicles refilling.

Features:

1. One or three-way priority refilling system.

2. Single or double-hose dispensers.

3. Mass metering system per hose.

4. Refill presetting.

5. Working pressure: 250 bar.

6. Cut pressure: 200 bar adjusted as per your requirements.

7. Excess flow shut-down system.

8. Emergency shut-down system in case of high-pressure dispatch.

9. Break-away valves.

10. Emergency shut-down system.

11. Approved to work in Class I, Division I areas.

Technical parameters:

Item no. JKJQ-30-II, IV
Product standards GB/19237 JJG996-2012 Q/75595257-9.8-2014
Full performance test certificate 2015-001
Explosion proof certificate CNEx14.3295
EX mark Ex d e ib mbⅡB T4 Gb
Working medium CNG
Flow range(filling dispenser) (1～30)kg/min
Meter accuracy class 1.0
Max.working pressure 25Mpa
Rated working pressure 20Mpa
Input power AC 187V~242V 50±1Hz, P≤300W
Work enviroment Enviroment temperature:-35℃～+55℃
Relative humidity:≤95%
Ambient atmosphere:86～110kPa
unit of measurement dollar/kg dollar/m3
Weight,including package 220kg
