60W Quad output power supply +5V/+15V/-5V/-15V Q-60C
60W Quad output power supply +5V/+15V/-5V/-15V Q-60C
Specifications
Brand Name :
JH
Model Number :
Q-60C
Certification :
CE
Place of Origin :
China
MOQ :
1pc
Payment Terms :
T/T, Paypal, Western union
Supply Ability :
30000pcs per month
Packaging Details :
1pc/box
Output Voltage :
+5V/+15V/-5V/-15V
Output Frequency :
47~63Hz
Output Current :
5.5A/1.5A/0.5A/0.5A
Output Power :
60W
Output Type :
Quad
Input Voltage :
90~264VAC
Protection :
over voltage, over current, short circuit protection
Description

60W Quad output power supply +5V/+15V/-5V/-15V Q-60C

Features:

1. Full range AC input

2. Protection: over voltage, over current, short circuit protection

3. Heat from the cold

4. 100% full-load burn-in test

5. High quality and low price

Specification:

Model number Q-60B Q-60C
CH1 CH2 CH3 CH4 CH1 CH2 CH3 CH4
DC Output Voltage 5V 12V -5V -12V 5V 15V -5V -15V
Output Voltage Error ± 2% ± 6% ± 5% ± 5% ± 2% ± 5% ± 5% ± 5%
Rated Output Current 5.5A 2A 0.5A 0.5A 5.5A 1.5A 0.5A 0.5A
Output Current Range 0-5.5A 0-2A 0-0.5A 0-0.5A 0-5.5A 0-1.5A 0-0.5A 0-0.5A
Ripple and Noise 100mVp-p 120mVp-p 100mVp-p 120mVp-p 100mVp-p 120mVp-p 100mVp-p 120mVp-p
Inlet Stability ± 0.5% ± 1% ± 0.5% ± 0.5% ± 0.5% ± 2% ± 0.5% ± 0.5%
Load Stability ± 0.5% ± 4% ± 1% ± 1% ± 0.5% ± 4% ± 1% ± 1%
DC Output Power 60W 60W
Efficiency 70% 72%
Adjustable Range for DC Voltage CH1: +10, -5% CH1: +10, -5%
AC Input Voltage Range 90~264VAC 47~63Hz; 120~370VDC
Input Current 2A/115V 0.8A/230V
AC Inrush Current Cold-Start Current 18A/115V 36A/230V
Leakage Current ＜1mA/240VAC
Overload Protection 105%~135% Type: Cut Output, Reset: Auto Recovery
Over Voltage Protection 115%~135%
High-temperature Protection ................................
Temperature Coefficient ± 0.03% /°C (0~50°C) ON+5V
Start, Rise, Hold time 800ms, 20ms, 60ms
Vibration 10~500Hz, 2G 10min/1 cycle, a total of 60 minutes, Each axes
Withstand Voltage Input and Output Interval: 1.5KVAC, Input and Enclosure: 1.5KVAC, Output and Enclosure: 0.5KVAC
Isolation Resistance Input and Output Interval: Input and Enclosure, Output and Enclosure: 500VDC/100M Ohms
Working Temperature and Humidity -10°C~+60°C, 20%~90%RH
Dimension 159*98*38 mm
Weight 0.56kg

Dimension unit:mm
