DR-60-15 single output DIN rail power supply 60W 15V 4A
DR-60-15 single output DIN rail power supply 60W 15V 4A
Specifications
Brand Name :
JH
Model Number :
DR-60-15
Certification :
CE
Place of Origin :
China
MOQ :
1pc
Payment Terms :
T/T, Paypal, Western union
Supply Ability :
30000pcs per month
Packaging Details :
1pc/box
Output Voltage :
15V
Output Frequency :
47~63Hz
Output Current :
4A
Output Power :
60W
Output Type :
Single
Input Voltage :
85~264VAC
Protection :
Over voltage, over current, short circuit protection
Description

DR-60-15 single output DIN rail power supply 60W 15V 4A

Features:

1. Full range AC input

2. Protection: Over voltage, over current, short circuit protection

3. Heat from the cold

4. 100% full-load burn-in test

5. Installation Guide: TS-35/7.5 or TS-35/15

6. High quality and low price

Specification:

Model number DR-60-5 DR-60-12 DR-60-15 DR-60-24
DC Output Voltage 5V 12V 15V 24V
Output Voltage Error ± 2% ± 1% ± 1% ± 1%
Rated Output Current 6.5A 4.5A 4A 2.5A
Output Current Range 0-6.5A 0-4.5A 0-4A 0-2.5A
Ripple and Noise 80mVp-p 120mVp-p 120mVp-p 150mVp-p
Inlet Stability ± 1% ± 1% ± 1% ± 1%
Load Stability ± 1% ± 1% ± 1% ± 1%
DC Output Power 32.5W 54W 60W 60W
Efficiency 74% 81% 82% 86%
Adjustable Range for DC Voltage +10% , -5% ± 10% ± 10% ± 10%
AC Input Voltage Range 85~264VAC 47~63Hz; 120~370VDC
Input Current 1.5A/115V 0.75A/230V
AC Inrush Current Cold-Start Current 25A/115V 50A/230V
Leakage Current <1mA/240VAC
Overload Protection 105%~150% Type: Cut Output, Reset: Auto Recovery
Over Voltage Protection 115%~135%
High-temperature Protection ................................
Temperature Coefficient ± 0.03% /°C (0~50°C)
Start, Rise, Hold time 100ms, 30ms, 100ms
Vibration 10~500Hz, 2G 10min/1 cycle, a total of 60 minutes, Each axes
Withstand Voltage Input and Output Interval: 1.5KVAC, Input and Enclosure: 1.5KVAC, Output and Enclosure: 0.5KVAC
Isolation Resistance Input and Output Interval: Input and Enclosure, Output and Enclosure: 500VDC/100M Ohms
Working Temperature and Humidity -10°C~+50°C, 20%~90%RH
Dimension 93*78*56 mm
Weight 0.28kg

Dimension unit:mm
